5
Remove the screws from the front of the LCD panel assembly.
Important
The number of screws varies by convertible notebook model.
Screw
Screw
Screw
6
Carefully separate the front and back of the LCD panel assembly.
7
Disconnect the power button cable from the power button board.
www.gateway.com
Screw
Screw
Screw
Screw
Screw
Connector
35
