Replacing the tablet button board

Tools you need to complete this task:
v
Screws removed during this task:
To replace the tablet button board:
1
2
3
4
www.gateway.com
Flat-blade driver
Phillips #0 screwdriver
4 or 8 black 2.5*5.0 (LCD
panel front)
Complete the steps in "Preparing the convertible notebook" on page
Remove the keyboard cover by following the steps in
page 27.
Open the LCD panel to the fully open position.
Remove the rubber inserts from the front of the LCD panel assembly.
Important
The number of rubber inserts varies by convertible notebook model.
Insert Insert
Insert Insert
- OR -
2 chrome 2.5*6.0
(Tablet button board)
"Replacing the keyboard cover" on
Insert Insert
Insert Insert
Scribe or non-marring tool
5.
