Gateway Convertible Service Manual page 51

9
Remove the screws connecting the LCD panel to the LCD lid.
Screw
Screw
10
Remove the old LCD panel from the LCD lid.
11
Place the new LCD panel into the LCD lid.
12
Replace the screws removed in
13
Feed the wiring back into the hinge.
Tip
Start by feeding the wire that has the largest connector into the hinge. Then
proceed to the wire that has the next smallest connector and so on.
14
Reconnect the tablet button board by following the instructions in
button board" on page
15
Reconnect the inverter and reassemble the LCD assembly by following the instructions in
"Replacing the inverter" on page
16
Replace the LCD assembly by following the steps in
17
Replace the keyboard cover by following the steps in
page 27.
18
Replace the hinge covers by following the steps in
19
Reconnect the antenna wires to the wireless card by following the steps in
IEEE 802.11 wireless card" on page
20
Replace the wireless bay cover by following the steps in
card" on page 16.
www.gateway.com
Step 9.
37.
31.
16.
Screw
"Replacing the tablet
"Replacing the LCD assembly" on page
"Replacing the keyboard cover" on
"Replacing the hinge covers" on page
"Replacing the IEEE 802.11 wireless
Screw
40.
26.
"Replacing the
47
