Replacing convertible notebook components
If you are removing a memory module, gently press outward on the clip at each end of the
module until the module tilts upward.
Clip
Pull the module out of the slot.
Hold the new or replacement module at a 30-degree angle and press it into the empty
memory slot. This module is keyed so it can only be inserted in one direction. If the module
does not fit, make sure that the notch in the module lines up with the tab in the memory bay.
Press the card down until it clicks into place.
Replace the memory bay cover, then tighten the cover screws.
Clip
