Gateway Convertible Service Manual page 53

9
Remove the LCD panel hinge by following the instructions in
on page 43.
10
Remove the screws connecting the LCD panel to the old LCD lid.
Screw
Screw
11
Remove the LCD panel from the old LCD lid.
12
Place the LCD panel into the new LCD lid.
13
Replace the screws removed in
14
Replace the LCD panel hinge by following the instructions in
on page 43.
15
Replace the tablet button board by following the instructions in
board" on page 37.
16
Replace the power button board by following the instructions in
board" on page 34.
17
Replace the inverter and reassemble the LCD assembly by following the instructions in
"Replacing the inverter" on page
18
Replace the LCD assembly by following the steps in
19
Replace the keyboard cover by following the steps in
page 27.
20
Replace the hinge covers by following the steps in
21
Reconnect the antenna wires to the wireless card by following the steps in
IEEE 802.11 wireless card" on page
22
Replace the wireless bay cover by following the steps in
card" on page 16.
www.gateway.com
Step 10.
31.
16.
"Replacing the LCD panel hinge"
Screw
"Replacing the LCD panel hinge"
"Replacing the tablet button
"Replacing the power button
"Replacing the LCD assembly" on page
"Replacing the keyboard cover" on
"Replacing the hinge covers" on page
"Replacing the IEEE 802.11 wireless
Screw
40.
26.
"Replacing the
49
