Features - Automatic Technology GDO-6v3 EasyRoller Installation Instructions Manual

Features

Thank you for purchasing the Automatic Technology
EasyRoller®
Designed by our renowned engineers to suit Vertical
Operating Continuous Curtain Roll up doors, the
EasyRoller® will provide years of smart, simple
& secure convenience to your home.
Operation
To open or close the door simply press a button on a TrioCode™ handheld
transmitter, a wall mounted transmitter, or optional wall switch for two seconds.
During open and close cycles the door can be stopped by pressing the button
again. The next actuation will move the door in the opposite direction.
TrioCode™ Code Hopping Technology
Every time a TrioCode™ transmitter is used, a new security code is randomly
generated from over 4.29 billion possibilities. This greatly enhances the security of
the system and makes "code grabbing" a thing of the past.
These transmitters also overcome interference issues by simultaneously sending a
signal over three slightly different frequencies. Even if two of the three signals are
jammed, the system will still work.
ALPS (Automatic Limits Positioning System)
ALPS does away with manual adjustment of the door's limits position using mechanical
parts, such as cams and microswitches. During installation the handheld transmitter can be
programmed to set the door limits positions.
ISS (intelligent safety obstruction system)
While the door is performing a close cycle, should it hit an obstacle or be restricted in some manner, it
will automatically reverse. The amount of force the door should encounter before reversing is automatically
adjusted by the doors control system during the initial installation of the automatic door opener. The door will
also stop if restricted whilst opening. The Safety Obstruction Force should be checked monthly.
Auto courtesy light
The courtesy light comes on automatically for three minutes whenever the door is activated. The light can also
be operated independently of the door by coding a dedicated button on a transmitter.
GDO-6v3 EasyRoller
6
Automatic
® Owner Installation Instructions
Garage Door Opener.
