Parameters

Button Functions

Buttons
OPERATE
DOOR CODE
LIGHT CODE
FORCE MARGIN SET & OPEN
FORCE MARGIN SET & CLOSE
FORCE MARGIN SET (then) SET
AUTO CLOSE TIME (then) OPEN
AUTO CLOSE TIME (then) CLOSE
AUTO CLOSE TIME (then) SET
CLOSE (for 6 secs.)
SET & CLOSE (for 2 secs.)
SET (then power on) & hold until all LED's are off
DOOR CODE (then power on) & hold until all LED's
are off
SET & DOOR CODE (the power on) and hold until all
LED's are off
SET
Function
Opens/Stops/Closes the door
Codes a transmitter button for operate, vacation
and pet functions
Codes a transmitter button for light function
Increases the obstruction force margin setting
Decreases the obstruction force margin setting
Resets the factory default force margin settings
Increases the Auto-Close delay time
Decreases the Auto-Close delay time
Resets the factory default Auto-Close delay time
Clears the door limits set positions. Limits then
need to be reset
Enters pet (pedestrian) position mode
Deletes control parameters excluding transmitter
storage memory
Deletes all transmitter storage memory
Deletes all control parameters and transmitter
storage memory.
Re-initialises the Opener to re-calculate force
margin
