Features - Automatic Technology GDO-9 Dynamo Gen 2 Owner's Manual

4 GDO-9 Dynamo

2. Features

Warranty
Two (2) year/5,000 cycles full parts and labour
warranty on motor, electronics and mechanical
components of the opener when installed by an
Automatic Technology Dealer.
TrioCode Frequency Hopping Technology
Every time a transmitter is used, it simultaneously
sends a signal over three different frequencies,
reducing the chance of interference from other
radio frequency sources.
Code Hopping Technology
Every time a transmitter is used a new security
code is generated from over 4.29 billion possible
code combinations. This greatly enhances the
security of the system and makes "code grabbing"
a thing of the past!
Multi-Channel Transmitter
Multi-channel transmitters allow you to operate
other devices such as an adjoining garage door
or automated gate from the same handy unit.
Safety Reversing System
The automatic safety reverse system significantly
reduces the risk of
trapped by a closing door. The safety reverse force
can be adjusted for environmental conditions
such as windy areas.
Memory Retention
In case of a power failure the opener does not
lose the transmitter codes or limit settings.
Soft Start/Soft Stop
The opener eases into and out of each cycle
making for smoother and quieter operation, as
well as reducing wear and tear on the door and
opener.
Manual Release
The manual release handle allows the door to be
operated by hand in the event of a power failure.
Self Locking
There is no need to manually lock your garage
door, as the opener 'positively' locks the door
when closed.
TM GEN2 Home Owner's Manual
death or serious injury if
Service Indicator
The opener has a built in service counter. From
factory this is loaded with 3000 cycles. When
this counter expires, the service yellow LED will
light up and at the start of each door movement
the beeper will sound three times. Contact your
dealer/installer for service. (Refer to 10.5 for
information).
Service Fault Indicator
Flashing LEDs on the control panel easily identify
operational problems or service requirements.
Dynamic Door Profiling
Changing door characteristics are automatically
compensated for and "learnt" with each
operation of the door.
Safety Beam (Optional)
The opener has an input to connect a Safety
Beam for extra safety and use of the Auto-Close
mode. Safety Beam PE 3 kit or Wireless Safety
Beam kit can be used with this opener.
SmartSolar™ and Battery Backup
Compatibility (Optional)
The opener can be fitted with a SmartSolar™ or
Battery Backup kit for operation in the event of
a power outage, or where mains power access is
not available.
Auto Courtesy Light
The courtesy light comes on automatically for
three minutes whenever the door is activated.
The light can also be operated independently
of the door by coding in a dedicated button on
a transmitter. (Refer to 8.2 for information)
Vacation Mode
A transmitter can be programmed to disable
the garage door opener radio receiver. This is
ideal if the door is to be left idle for prolonged
periods. (Refer to 8.3 for information)
Pet (Pedestrian) Mode
A transmitter can be programmed to open
the door partially to allow pets access to the
garage. The door opening height is adjustable
via a handheld programmer (contact your
dealer for further information).
