CAUTION: After connectng the DC power cable, NMEA IN/
OUT leads, external speaker lead and haler/foghorn lead,
cover the connector and leads wth an adhesve tape as
shown below, to prevent water seepng nto the transcever.
Rubber vulcanizing
tape

■ Fuse replacement

One fuse s nstalled n the suppled DC power cable. If a
fuse blows or the transcever stops functonng, track down
the source of the problem f possble, and replace the dam-
aged fuse wth a new one of the proper ratng.
Fuse rating: 10 A
CONNECTIONS AND MAINTENANCE

■ Supplied accessories

Mounting bracket For mounting bracket
Knob bolts
Screws (5×20)
Microphone* For microphone
Connection cable*
(OPC-1000: 6m; 20 ft)
*Depending on version
Microphone hanger
DC power cable
and screws (3×16)
(OPC-891A)

■ Antenna

A key element n the performance of any communcaton
system s the antenna. Ask your dealer about antennas and
the best place to mount them.
9
Flat washers (M5)
Spring washers (M5)
Mounting base*
9
Tapping screws*
(M3×16)
Warning
sticker
