Regardless of a GPS recever (NMEA0183 ver. 2.0 or
3.01) connecton, the current poston/tme nformaton
appears n steps r and t. If the nformaton s not nec-
essary to be changed, push [DIAL•ENTER] or [16•9]
several tmes to skp the data nput steps.
r The poston nformaton appears. Set your poston (lat-
tude and longtude) data by rotatng [DIAL].
• Push [16•9] or [CH/WX•DUAL•U/I/C] to move the cursor for-
ward or backward, respectvely.
• Rotate [DIAL] to edt N; North lattude or S; South lattude when
the cursor s on the 'N' or 'S' poston, and W; West longtude or
E; East longtude when the cursor s on the 'W' or 'E' poston.
• Push [CLR] for 1 sec. to clear the lattude/longtude data.
• Push [CLR] to cancel and return to the DSC menu.
--DSC Menu--
Input Position
Latitude
__ __.___N
Longitude
__ __.___W
<CLR 1sec Null Data>
<CLR Exit / ENT OK>
t After settng the poston data, push [DIAL•ENTER] to set
the current UTC tme. Set the current UTC tme by rotat-
ng [DIAL], then push [DIAL•ENTER].
• Push [16•9] or [CH/WX•DUAL•U/I/C] to move the cursor for-
ward or backward, respectvely.
• Push [CLR] for 1 sec. to clear the UTC tme data.
• Push [CLR] to cancel and return to the DSC menu.
Null
Null
--DSC Menu--
Input UTC Time
__:__
<CLR 1sec Null Data>
<CLR Exit / ENT OK>
y Push [DISTRESS] for 5 sec. to transmt the dstress call.
• Whle pushng [DISTRESS], the key backlghtng blnks.
u After transmttng the dstress call, the transcever wats
for an acknowledgment call on Channel 70.
• The dstress call s automatcally transmtted every 3.5 to 4.5
mn.
• After 2 sec., the transcever s set to Channel 16 automatcally.
Distress Call
TX Complete
Now Waiting for ACK
<CLR Cancel>
25W
TAG
After 2 sec.
Wait ACK
<CLR
Cancel>
6
DSC OPERATION
Null
INT
CALLING
6
25
