Digi-3-Coder (Issue 1.2)
Digi-3-Coder Electrical Installation Details
Connection Socket
ON / OFF Switch
Connecting Box
(Fitted with solenoid Valve)
Mains Input Cable
Supply 110 - 230 Volts AC
(Auto-sensed)
6 October 2005
(Double pole)
Fuse 2amp Anti-Surge (Part No. FUS 503512)
Cable Socket Assembly
There are 3 spare Cable glands,to allow
connecting of Print Signals,Fault relays
and Air Switches etc.
Page 9
Digi-3-Coder
(Part No. CAB 313019)
1.5 Metres Long
