Digi-3-Coder (Issue 1.2)
Digi-3-Coder Pneumatic Installation Details
6mm "BLACK" Nylon Tubing
Connecting Box
(Fitted with solenoid Valve)
6 October 2005
Page 8
Digi-3-Coder
6mm "RED" Nylon Tubing
Air Supply, 4 to 6.8 Bar
(6 mm NylonTubing)
