Digi-3-Coder Operator Instructions
MAGAZINE REMOVAL (See pages 7 & 18)
To remove the foil magazine, slide the catch away from the type holder access door,
hold in place and withdraw the magazine using the two handles.
FOIL THREADING (See page 18)
1. Fit an empty foil core onto the rewind mandrel.
2. Disengage the pinch drive roller.
3. Remove label from a new roll of foil.
4. Fit new roll of foil onto take-off mandrel (note unwind direction as shown on
threading diagram).
5. Thread foil around all rollers as shown on threading diagram. Note, the gloss
side of the foil should face inwards throughout the foil path.
6. Attach end of foil to empty core on rewind mandrel, gloss side facing inwards.
7. Wind foil on a few turn to track and tension it.
8. Engage pinch drive roller.
RE-FITTING FOIL MAGAZINE
Hold the magazine by the two handles, slide onto the locating pins and push to lock in
place. Press the PRINT switch on.
FITTING TYPE/DIE HOLDER
"Never assume that a Type/die holder is cold"
Only pick up a type/die holder by its handle. Ensure that the face of the magnetic catch
is clean. Open the red type holder access door (the alarm will sound continuously),
align the type/die holder within the two side locators and slide in until the magnet
catches on the end plate. Close the door. (Alarm stops sounding)
FOIL FEED ADJUSTMENT (See pages 15 & 16)
This is used to adjust the amount of foil used per print, adjusting the print index button
to achieve the correct index required. A gap of 1 or 2mm is recommended between
each section of used foil.
