Digi-3-Coder (Issue 1.2)
NOTE
The standard Digi-3-Coder is calibrated at 130ºC or 266°F
Unless you are changing the temperature to the extremes, the default calibration should be
left alone.
Calibration & Temperature Range:= 70ºC to 220ºC (158ºF to 428ºF)
External Calibration Method
1. Switch the Digi-3-Coder unit on and adjust the temperature setting to 130ºc or 266ºF.
2. Leave on for 10 to 15 minutes, allowing the temperature to stabilise.
3. Measure the temperature at the type face using a temperature probe.
4. Allow the temperature probe to stabilise before noting the reading.
5. Adjust the Digi-3-Coder set point to match the temperature probe reading.
6. Press both the up and down arrow keys at the same time, then press the print switch.
7. The controller is now calibrated.
Note.
Calibration may have to be repeated, for accuracy of temperatures.
"For operating temperatures above 180ºc or 356ºF calibrate at 200ºC or 392ºF"
6 October 2005
Digi-3-Coder Calibration Method
Page 39
