Open Date Digi-3-Coder Operator Instructions Manual page 36

Digi-3-Coder (Issue 1.2)
Digi-3-Coder Essential Spares List
Description
1. Cassette Brake Tension Spring (2 off)
2. Timing Belt (Digi-3-Coder)
3. Drive Roller Assembly
4. Cassette Take Up Belt (2 off)
5. Cassette Brake Strap
6. Grey Self Adhesive Print Base
300 x 450mm sheet
or
7. White Silicone Rubber Print Base
300 x 300 x 3mm thick sheet
8. Cartridge Heater (240v x 500watt)
9. Thermistor Probe (Digi-3-Coder)
10. Reed Switch (Door Sensor)
11. Low Foil Sensor Assembly
12. Pack of Mains Fuses (5) 2Amp Anti-Surge
Digi-3-Coder Comprehensive Spares List
Description
1. Cassette Brake Tension Spring (2 off)
2. Timing Belt (Digi-3-Coder)
3. Drive Roller Assembly
4. Cassette Take Up Belt (2 off)
5. Cassette Brake Strap
6. Grey Self Adhesive Print Base
300 x 450mm sheet
or
7. White Silicone Rubber Print Base
300 x 300 x 3mm thick sheet
8. Cartridge Heater (240v x 500watt)
9. Thermistor Probe (Digi-3-Coder)
10. Reed Switch (Door Sensor)
11. Low Foil Sensor Assembly
12. Pack of Mains Fuses (5) 2Amp Anti-Surge
13 Main Circuit Board (Digi-3-Coder)
14. Membrane Assembly (Including PCB)
15. Solenoid Valve without fittings
16. Ribbon Motor Assembly
17. Cable Socket 1.5 Metre Long (Connecting Box)
6 October 2005 Page 36
Part No.
SPR 530008
BEL 762064
DRI 620204
DRI 110022
BRA 311031
SABASE
SRBASE
HEA 312070
THE 312080
REE 312107
SEN 312086
FUS 393502
Part No,
SPR 530008
BEL 762064
DRI 620204
DRI 110022
BRA 311031
SABASE
SRBASE
HEA 312070
THE 312080
REE 312107
SEN 312086
FUS 393502
PCB 312060
KEY 312090
VAL 312034
MOT 312087
CAB 313019
