Digi-3-Coder (Issue 1.2)
Digi-3-Coder Dip Switch Settings & Explanations
The dip switches are located behind the membrane, inside the printer.
Access by removing the side guard of the printer.
6 October 2005
Default Dip Switch Settings
Europe
1 = OFF
2 = OFF
3 = OFF
4 = ON
Description of Switches
1 = CENT/FAHR
Off = Centigrade,
ON = Fahrenheit
2 = THERMISTOR 1/2
Off = USP Thermistor (Standard)
ON = Alternative Thermistor
3 = FOIL ON/OFF
Off = Foil Sensor Fitted.
ON = Not Fitted
4 = TEMP STOP YES/NO
Off = Prints only within temperature range
ON = Prints at any temperatures.
Page 26
USA
1 = ON
2 = OFF
3 = OFF
4 = ON

Dip Switch Location

(enlarged view)
