Operating Specifications - Open Date Digi-3-Coder Operator Instructions Manual

Digi-3-Coder (Issue 1.2) 6 October 2005 Page 5
Operating Specifications for Digi-3-Coder
Supply Voltage (Autosensed)
Nominal 230v AC, plus or minus 10% tolerance (207 – 253). 50 or 60 Hertz.
Nominal 115v AC, plus or minus 5% tolerance (109 – 121). 50 or 60 Hertz.
Heater
Single Cartridge Heater, 240 Volt AC, 500 Watt. (Part No. HEA 312070)
Normal temperature range: 70ºC to 220ºC, or 158ºF to 428ºF
Thermistor
Model No. USP5362 (Part No. THE 312080)
Output Relay Contacts
Fault Relay:- Rated at 24V DC, 1 amp current.
Print Relay:- Rated at 24V DC, 1 amp current.
(Both relays utilise common, normally open or normally closed contacts)
Input Print Signals
Voltage Free contacts. (microswitch, relay or plc etc.)
Voltage 10 – 30 Volts AC or DC (polarity unimportant)
Microprocessor
PIC Micro-Processor type:-.
Controlled by a specific designed membrane panel with inbuilt switches etc.
The temperature display is seen through a translucent panel on the membrane.
Solenoid Valve Output
24 Volt DC, 80mA current normally. (Part No. VAL 312034)
Air Pressure required
4.0 to 6.8 bar
Air Consumption
231cc @ 6.8 bar free air per cycle.
Foil Capacity
153 Metres (500 feet)
Foil Indexing
2mm to 16mm in 0.1mm increments. (0.078" to 0.625" in 0.005" Increments)
Dwell Time
10 to 2000 milliseconds.
Print Signal Delay
0 to 999 milliseconds. (Indicated by flashing green LED if activated)
