Digi-3-Coder (Issue 1.2)
Digi-3-Coder Connection Box (Parts Listing)
ITEM PART NUMBER
1 BOX 312033
2
PLA 312083
3 ELE 312042
4 GLA 313004
5
GLA 312041
6 NUT 312040
7
8
9 VAL 312034
10 VAL 312035
11
12
13
14
15 PCB 313006
16 WAS 311015
17
18
6 October 2005
(Part No. BOX 312085)
M3SCS08
M4CSS30
M3WAS
M4WAS
M4NUT
M3NUT
M3STS06
M3STS10
DESCRIPTION
Machined Connection Box
Gland Plate
Switch Rocker
Cable Gland Skintop M16
Cable Gland
Lock Nut
M3 Socket Cap Screw x 08 Long
M4 Counter Sunk Screw 25 Long
Solenoid Valve
Flow Control Valve
M3 Stainless Steel Washer
M4 Stainless Steel Washer
M4 Full Nut
M3 Full Nut
OEM Connections Assembly
Washer Top
M3 Self Tapping Screw x 06 Long
M3 Self Tapping Screw x 10 Long
Page 33
QTY.
1
1
1
1
5
5
4
2
1
2
4
4
4
4
1
2
4
4
