Digi-3-Coder (Issue 1.2)
Digi-3-Coder Installation Procedures
Do not connect the mains supply until you have ensured that correct voltage is being
supplied. (See page 5, Operating Specifications)
If the printer is fitted to a stand alone bracket provided by Open Date Equipment Limited,
connect the electrical supply as required. Connect a 6mm air pipe to the solenoid valve. The
air supply should be fitted with an Air Filter Regulator, not supplied by Open Date
Equipment.
Note!
The air supply received must be clean and dry, any moisture may damage the printer.
Procedures
1. Mount the printer into the frame.
2. Ensure the printer is approximately parallel to the print base, and the
clearance under the printer is approximately 5mm. (See page 7)
3. Place and secure the connecting box in a suitable position, ensuring the cable
socket reaches the printer. (see page 8)
4. Connect the two 6mm air pipes (red & black) to the solenoid valve & the
Printer (see page 8)
5. Connect a 6mm air supply pipe from the solenoid valve to a dry air supply,
through an Air Filter Regulator to control the pressure required. (see page 8)
Note!
Ensure all cables and air pipes are properly fed and do not obstruct the substrate or
printer movements.
Connections
Mains Supply (see pages 5, 9 & 24)
Trigger/Print Signal (see pages 5, & 24)
Solenoid Valve (see pages 12 & 24)
Relays (see pages 10 & 24)
Low Air (see pages 11 & 24)
Settings and Calibration
Dip switch Settings (see page 26)
Calibration of Printer (see page 39)
6 October 2005 Page 6
