Digi-3-Coder (Issue 1.2)
Digi-3-Coder Printer Spare Parts Listing
ITEM PART NUMBER
1 PLA 312030
2 BLO 312018
3 SPA 312023
4 M4CSS40
5 SPA 312024
6 SEN 312086
7 M4SCS16
8 SPA 312022
9 CYL 312068
10 TUB 312073
11 TUB 312074
12 PUL 312036
13 M3SCS12
14 M6SCS60
15 M4WAS
19 M6SCS20
20 GRO 312047
21 M3SCS25
22 BLO 312019
24 LOC 312012
25 PLA 312081
26 GUA 312053
27 M4NUT
28 PCB 312060
29 M4CSS12
30 ASY 312091
31 M3SCS06
32 PLA 312038
33 PLU 313012
36 MOT 312087
37 BEA 312089
38 PLA 312094
39 PLA 312095
REE 312107
40
41 SPA 312082
42 BLO 312106
43 WAS 312039
44
SCR 312110
45 M5SCS16
46 M4SCS08
47 FUS 503506
6 October 2005
DESCRIPTION
Plate Digi-3-Coder Body
Rear Guard Block
Plate Spacer
M4 Countersunk Screw 40 Long
P C B Short Spacer
Assembly Foil Sensor
M4 Socket Cap Screw x 16 Long
Cassette Location Spacer
Cylinder Assembly
Red Air Tube
Black Air Tube 6
48 Teeth Pulley
M3 Cap Screw x 12 long
M6 Socket Cap Screw x 60 Long
M4 Stainless Steel Washer
M6 Socket Cap Screw 20 Long
4mm Hole Grommet
M3 Socket Cap Screw x 25 Long
Front Block
Taperered Location Rod
Plate Guard Air
Guard Protection
M4 Full Nut
Main Assembly PCB
M4 Counter Sunk Screw 12 Long
Side Guard Assembly
M3 Cap Screw x 6 Long
Plate Cylinder
Plug 19 Way (Trident)
Assembly Ribbon Motor
Bearing Block Assembly
Plate Coder Support Assembly
Plate Cylinder Location Assembly
Reed Switch Assembly
Sensor Spacer
Block Air Connection Assembly
Washer Cassette Stop
M5 Shoulder Screw
M5 Cap Screw x 16 Long
M4 Cap Screw x 8 Long
Fuseholder
Page 31
QTY.
1
1
5
5
5
1
1
2
1
1
1
1
3
2
8
2
1
1
1
2
1
1
2
1
1
1
8
1
1
1
1
1
1
1
1
1
1
4
2
6
1
