Digi-3-Coder (Issue 1.2)
6 October 2005
Page 7
Digi-3-Coder Standard Frame Installation
Locking Handle
Levelling Nuts, both ends
Standard Eurocode Frame
Cassette Release Catch
(Lift Up)
Print Centre Line
Print Base
Maximum 5 mm Gap for Safety
Ensure the Nip Roller is fully engaged.
(Rotate Clockwise until it stops)
Positioning Handle
