Digi-3-Coder (Issue 1.2)
Digi-3- Coder (Wiring Connections) Trident 19 Way Plug on Printer
Signal
Mains Neutral
(Part No. PIN 508218)
20 AWG
Mains Live
(Part No. PIN 508218)
20 AWG
Mains Earth
(Part No. PIN 508218)
20 AWG
Screen/Trace
(Part No. PIN 508218)
20 AWG
Volt free trigger 1
(Part No. PIN 508219)
24 AWG
Volt free trigger 2 (GND)
(Part No. PIN 508219)
24 AWG
Isolated Voltage trigger 1
(Part No. PIN 508219)
24 AWG
Isolated Voltage trigger 2
(Part No. PIN 508219)
24 AWG
Fault relay Common
(Part No. PIN 508219)
24 AWG
Fault relay NO
(Part No. PIN 508219)
24 AWG
Fault relay NC
(Part No. PIN 508219)
24 AWG
Print relay Common
(Part No. PIN 508219)
24 AWG
Print relay NO
(Part No. PIN 508219)
24 AWG
Print relay NC
(Part No. PIN 508219)
24 AWG
Air fail volt free 1
(Part No. PIN 508219)
24 AWG
Air fail volt free 2 (GND)
(Part No. PIN 508219)
24 AWG
Solenoid +
(Part No. PIN 508219)
24 AWG
Solenoid - (GND)
(Part No. PIN 508219)
24 AWG
6 October 2005
No.
Wire type
2
0.5mm
2
0.5mm
2
0.5mm
2
0.5mm
2
1
0.22mm
2
2
0.22mm
2
3
0.22mm
2
4
0.22mm
2
5
0.22mm
2
6
0.22mm
2
7
0.22mm
2
8
0.22mm
2
9
0.22mm
2
10
0.22mm
2
11
0.22mm
2
12
0.22mm
2
13
0.22mm
2
14
0.22mm
Pin No.
Colour
F
BLUE
G
BROWN
GREEN/YELLOW
H
J
GREEN
T
GREEN
S
YELLOW
R
WHITE
E
BLACK
K
ORANGE
U
BROWN
V
GREY
P
PINK
D
GREY/ BLUE
C
MAUVE
L
YELLOW/RED
N
GREEN/RED
A
RED
B
BLUE
Page 23
Length
70mm
80mm
70mm
70mm
75mm
75mm
85mm
85mm
90mm
90mm
100mm
100mm
110mm
110mm
115mm
115mm
125mm
125mm
