Before You Begin - 3Com 3C509B User Manual

18 C
HAPTER
Table 3
and maximum network segments for the various
3C509B NIC models.
Table 3 Parameters for 3C509B NIC Models
NIC Model
3C509B-TPO
3C509B-TPC
3C509B-TP
3C509B-COMBO

Before You Begin

Before you install the 3C509B NIC, verify that you have
all of the components. If any of these items are damaged
or missing, contact your shipper or network supplier.
I
I
I
I
1: N I
ETWORK NTERFACE
shows the cable, connector, transceiver,
Cable
Category 3, 4,
or 5 unshielded
twisted-pair
(10BASE-T)
Category 3, 4,
or 5 unshielded
twisted-pair
(10BASE-T)
10BASE2 thin
Ethernet coaxial
Category 3, 4,
or 5 unshielded
twisted-pair
(10BASE-T)
10BASE5 thick
Ethernet coaxial
Category 3, 4,
or 5 unshielded
twisted-pair
(10BASE-T)
10BASE5 thick
Ethernet coaxial
10BASE2 thin
Ethernet coaxial
EtherLink 10 Mbps ISA NIC (3C509B)
EtherLink 10 Mbps ISA Network Interface Card
User Guide (this guide)
Quick Guide for the EtherLink 10 Mbps ISA
Network Interface Card
3Com 3C509B EtherDisk diskettes 1 and 2
C I
ARD NSTALLATION
Connector Transceiver
RJ-45 On-board
RJ-45 On-board
BNC On-board
RJ-45 On-board
15-pin AUI External
RJ-45 On-board
15-pin AUI External
BNC On-board
Maximum
Network
Segment
328 ft/100 m
328 ft/100 m
605 ft/185 m
328 ft/100 m
1640 ft/500 m
328 ft/100 m
1640 ft/500 m
605 ft/185 m
