To run the Group 3 test on the network, you need a second
PC to serve as an echo server, and it must have a 3Com NIC
installed. The echo server receives packets from and echoes
packets back to the NIC being tested. The diagnostics
program provided with the NIC supports the 3C509B echo
server diagnostics program.

Setting Up an Echo Server

Follow these steps to set up an echo server:
1 Insert the EtherDisk diskette for the echo server NIC
in drive A of the echo server.
2 Start the diagnostics program on the echo server.
The diagnostics program that you use is dictated by the
NIC that is installed in the echo server. See
DOS prompt, enter the diagnostics program name for the
associated NIC.
Table 10 Diagnostics Programs
Diagnostics
Program Name
3C503.EXE
3C505.EXE
3C507.EXE
3C508CFG.EXE
3C5X9CFG.EXE
3C523.EXE
3C523TP.EXE
3C527.EXE
3C59XCFG.EXE
3C90XCFG.EXE
The main window of the diagnostics program is displayed.
3 From the Test menu, select Echo Server, and then
click Start.
A message confirms that your PC is now set up as an
echo server.
Diagnostic Testing Under Windows 3.x
NIC Installed in the Echo Server
EtherLink II or II TP, EtherLink II/16 or II/16 TP
EtherLink Plus
EtherLink 16 or EtherLink 16 TP
3Com Red
EtherLink 10 family
EtherLink/MC
EtherLink/MC TP
EtherLink/MC 32
EtherLink 10 EISA/PCI bus master family
(including Fast EtherLink NIC running at
10 Mbps)
EtherLink XL and Fast EtherLink XL family of NICs
running at 10 Mbps
105
Table 10. At the
