Starting the Group 3 Test

Follow these steps to run the Group 3 test on the
3C509B NIC:
1 Start the Configuration and Diagnostics Program on
the PC in which the NIC to be tested is installed.
2 From the Test menu, select Test Setup.
3 Enable the Group 3 test. Select OK and press Enter.
4 Go to the Run Tests dialog box to start the tests.
5 After the test is completed:
a Exit the program on the echo server.
b Exit the Configuration and Diagnostics Program.

Getting Help If a Test Fails

If a diagnostic test fails, the NIC may not be defective. The
problem may be incorrect configuration settings, settings
that conflict with other NICs, or improper installation.
For more information about a failed diagnostic test:
I
I
CAUTION: If you intend to remove the NIC from your PC,
make sure to turn the power off before removing or
reinserting the NIC.
7: T
ROUBLESHOOTING FOR
Select the test that failed in the Run Tests dialog box
and press Enter.
Select the Zoom button and press Enter.
