  • Page 1 IP CamSecure Table of Contents IP CamSecure User’s Manual Ver. 1.20 -090817 Copyright (c) 2009 Digital Data Communications Co., Ltd. All Rights Reserved. page-1...

  • Page 2: Table Of Contents

    IP CamSecure Table of Contents TABLE OF CONTENTS TABLE OF CONTENTS....................2 SYSTEM REQUIREMENT ....................9 INSTALLATION......................10 Server Application Installation ..............10 Remote Desktop Tool..................16 DVR Driver Installation ..................19 PDA Client Installation..................21 Smart Phone Client Installation ..............22 QUICK START ......................
  • Page 3 IP CamSecure Table of Contents 1.5 Live Display ....................38 2. PLAYBACK ......................39 2.1 Information Window ................. 41 2.2 Audio Volume Control ................41 2.3 Screen Division ................... 41 2.4 Browse Mode....................41 2.5 Open Record ..................... 41 2.5.1 Date Time Panel ................. 42 2.5.2 Record Display Window..............
  • Page 4 IP CamSecure Table of Contents 2.14.1 Add Remote Playback Site............58 2.14.2 Access Remote Playback Site............58 3. SCHEDULE......................59 3.1 Day Mode ....................60 3.1.1 Load Preset Modes ................60 3.1.2 Insert a New Schedule Manually ............ 62 3.1.3 Copy Schedule ................... 62 3.2 Week Mode ....................
  • Page 5 IP CamSecure Table of Contents 4.2.6 Action Type - PTZ Preset Go ............. 84 4.2.7 Action Type – DI/DO ................85 4.2.8 Action Type –Send a SMS message ..........86 4.2.9 Action Type – Send to Central Server ..........86 4.2.10 Action Type –...
  • Page 6 IP CamSecure Table of Contents 6.1.1 Add/Edit/Delete Map ..............126 6.1.2 Add/Rotate/Delete Device Indicator .........127 6.2 Operate Mode..................129 6.2.1 Device and Map Tree list ..............129 6.2.2 E-Map picture ...................130 6.2.3 Information and Preview window..........130 6.3 Layout Adjustment ..................131 6.3.1 Adjust layout window ..............131 7.
  • Page 7 IP CamSecure Table of Contents 9.4.2 Enable Digital PTZ ................156 9.4.3 Stream Profile ..................156 9.4.4 Snapshot.....................156 9.4.5 Toggle Fullscreen ................156 9.5 Start Monitor .....................157 9.5.1 Multiple Monitor ................157 9.5.2 E-Map....................157 9.5.3 I/O Control ..................157 9.6 Playback ....................158 9.6.1 Add Remote Playback Site ............158 9.6.2 Access Remote Playback Site............158...
  • Page 8 IP CamSecure Table of Contents 1.3 PDA/Smart Phone Client Overview .............192 1.3.1 Live View ....................192 1.3.2 I/O Control ..................193 1.3.3 System Info ..................194 APPENDIX C - REMOTE DESKTOP TOOL .............195...

  • Page 9: System Requirement

    IP CamSecure System Requirement SYSTEM REQUIREMENT Total FPS 1200~600 600~480 480~240 240~120 120~0 at CIF Intel Core Intel Core Intel Intel P4 2.8 Intel P4 2.8 2 Quad 2 Duo Pentium D Q6600 E6400 2 GB 1 GB 1 GB...

  • Page 10: Installation

    IP CamSecure Installation INSTALLATION Install IP camera(s) Step 1: Set up the IP camera referring to the quick installation guide provided. Step 2: Check the network between the IP camera and the system. Step 3: Add the IP camera to the system. See details on later pages.
  • Page 11 IP CamSecure Installation Server IP CamSecure Installation Step 1: Insert the Installation CD. Step 2: The setup page should be loaded automatically. If it does not, please select your CD-ROM drive manually to open the setup page. Click “IP CamSecure” to initiate the installation.
  • Page 12 IP CamSecure Installation Step 4: Click Next to continuous. Step 5: Check the option “I accept the terms of the license agreement”. Click Next to continuous.
  • Page 13 IP CamSecure Installation Step 6: Please enter your name and the company name for which you work. Click Next to continuous. Step 7: Select “Complete Setup Type” or “Custom Setup Type” to install the System. COMPLETE SETUP TYPE Install all program features into the default directory.
  • Page 14 IP CamSecure Installation Check the option “Complete”, and then click “Next”. All program features will be installed. [Require the most disk space.] CUSTOM SETUP TYPE Install the system to a preferred directory. Or select whichever program feature(s) to install. This is recommended for advanced users.
  • Page 15 IP CamSecure Installation Step 8: Click install to start the installation. Step 9: Click Finish after installing the system completely.

  • Page 16: Remote Desktop Tool

    IP CamSecure Installation Remote Desktop Tool Remote Desktop Tool allow user remote to access Main Console System and setup configuration. Step 1: Insert the Installation CD. Run Setup.exe from the CD-ROM directory/RemoteDesktopViewer to start the installation. Step 2: In the InstallShield Wizard dialog box, click Next to continuous.
  • Page 17 IP CamSecure Installation work. Click Next to continuous. Step 5: Select “Complete Setup Type” or “Custom Setup Type” to install the System. COMPLETE SETUP TYPE Install all program features into the default directory. Check the option “Complete”, and then click “Next”. All program features will be installed.
  • Page 18 IP CamSecure Installation Select the features setup will install. Step 6: Click “Install” to start the installation. Step 7: Click “Finish” after installing the system completely.

  • Page 19: Dvr Driver Installation

    IP CamSecure Installation capture card Installation Driver Install Tool help user to auto detect type of capture card and install corresponding drivers. Step 1: Insert the Installation CD. Run InstallDrv.exe from the CD-ROM directly to start the installation. Step 2: In the CaptureCardDriver Setup Wizard dialog box, click Next to continuous.
  • Page 20 IP CamSecure Installation Step 6: Click “Finish” after installing the system completely, and then choose to reboot now or later.

  • Page 21: Pda Client Installation

    IP CamSecure Installation PDA Client Installation (Professionals version only) Step 1: Connect PDA device to the PC. Step 2: Insert the installation CD, Run Setup.exe from the CD-ROM directory/PDAClient to install PDA Client. Note: If you do not have Microsoft® ActiveSync installed, a message will appear “Can not find ActiveSync.

  • Page 22: Smart Phone Client Installation

    IP CamSecure Installation Smart Phone Client Installation (Professionals version only) Step 1: Connect Smart Phone device to the PC. Step 2: Insert the installation CD, Run Setup.exe from the CD-ROM directory/SPClient to install PDA Client. Note: If you do not have Microsoft® ActiveSync installed, a message will appear “Can not find ActiveSync.

  • Page 23: Quick Start

    **IP CamSecure Lite32 is free bundled with LevelOne IP camera and Capture Card. ** IP CamSecure professional version is available upon purchase. While using IP CamSecure Pro Mega v1.20 or later, please input the serial number as a license key to register on internet.

  • Page 24: Install Ip Camera(S)

    Add the IP camera(s) to the system by following steps. Add IP camera(s) Step 1: Go to Start > All Programs > LevelOne > Step 3 IP CamSecure > Main Console. Step 2: Type in user name and password and log in to the system. Step 3: In Main Console, go to Config >...
  • Page 25 IP CamSecure Quick Start Step 9: Enter the IP address or domain name (check the “Use DNS” option), Http Port, Username, and Password. Step 10: Click “Auto Detect” Step 11: Click OK to add the camera. Step 12: Click OK to exit Setting panel.

  • Page 26: Set Schedule

    IP CamSecure Quick Start Set Schedule Step 1: Go to Start > All Programs > LevelOne > IP CamSecure > Main Console. Step 2: Type in user name and password and log in the system. Step 3: Click on “Schedule".

  • Page 27: Set Smart Guard

    Quick Start Set Smart Guard Step 1: Go to Start > All Programs > LevelOne Step 3 > IP CamSecure > Main Console. Step 2: Type in user name and password and log in the system. Step 3: Click on “Guard”.

  • Page 28: Start Recording & Smart Guard

    IP CamSecure Quick Start Start Recording & Smart Guard Step 1: Go to Start > All Programs > LevelOne > IP CamSecure > Main Console. Step 3 Step 2: Type in user name and password and log in the system.

  • Page 29: Playback

    IP CamSecure Quick Start Playback Step 1: Go to Start > All Programs > LevelOne > IP CamSecure > Main Console. Step 2: Type in user name and password and log in the system. Step 3: Click on “Playback”. Step 4: In Playback, click on “Open Record”...

  • Page 30: Main Console

    IP CamSecure 1. MainConsole 1. Main Console This is the main operation system - to activate, schedule recording, setup smart guard and configure system setting. page-30...
  • Page 31 IP CamSecure 1. MainConsole Exit Minimize Screen Division Shut down the Surveillance System or log out current user. Minimize the Main Console window. Allocate the sub-screen display by clicking on the desired layout icon. To switch to single camera display, double click on a particular sub-screen.

  • Page 32: Start

    IP CamSecure 1. MainConsole 1.1 Start Start Click on the Start icon and select from the drop down menu to activate/ deactivate: (a) Recording Schedule System, (b) Smart Guard System, or (c) Counting Application. Or select Start/Stop Monitor All to activate/ deactivate all the functions at once.
  • Page 33 IP CamSecure 1. MainConsole 3. As for Secondary Display, open event report, open E-map window, open Resource Report and open IO controls panel, MainConsole will keep the behaviors as the latest status when exiting the system. Config Playback Schedule Guard Click on the icon to get Playback Console.

  • Page 34: Information Window

    IP CamSecure 1. MainConsole Select from the drop down menu to modify general setting, user account settings, save/ load configuration settings, open License Manager, edit counting application and POS application, access log viewer and backup files, or setup network services. See Config on page 88 for detail.

  • Page 35: Preset/ Go

    IP CamSecure 1. MainConsole 1.3.1 Preset/ Go Adjust the camera view until you are satisfied. Click on the Set icon and set up the view as the preset point 01. Adjust the camera view again and set up the preset point 02. Repeat the process until finish setting up all preset points.

  • Page 36: On Screen Menu

    IP CamSecure 1. MainConsole 1.4 On Screen Menu Right click on the camera screen and get the “On Screen Menu”, from which you can quickly adjust the setting of camera. 1.4.1 Enable Move With cameras that support PT function, click the “Enable move”...

  • Page 37: Delete Camera

    IP CamSecure 1. MainConsole 1.4.6 Delete Camera Click on Delete Camera to remove a camera from the display screen of the display screen. Note: 1. The camera list of delete camera menu shows as the one in the right column of monitor display panel.

  • Page 38: Live Display

    IP CamSecure 1. MainConsole 1.5 Live Display Live display is flexible to change channels and screen divisions. Each screen divisions have the same display list, but have the different sequence. Such like, when using Show/Duplicate/Delete Camera function to edit camera list, the operator will apply to all different screen divisions.

  • Page 39: Playback

    Watch the recorded video, view and/or search for unusual events and recorded system information. *There is only 1 channel displayed in Playback in IP CamSecure Lite32 while there are up to 16 channels displayed in IP CamSecure Pro/Pro Plus/Pro Mega simultaneously. page-39...
  • Page 40 Intelligent Surveillance Solution 2. Playback Scroll Bar Exit Minimize Control Speed Zoom FWD/REV: Customize the speed on Setting panel. Step FWD/REV: Forward/reverse frame by frame. Minimize the Playback console. Shut down the Playback console. Indicate the status of the playing video; drag it to where you want to review.

  • Page 41: Information Window

    IP CamSecure 2. PlayBack Browse Mode Search Mode Screen Division Open Record Audio Volume Control Information Window 2.1 Information Window Display video date and time, current video status, cue in/ out points’ time, and speed. 2.2 Audio Volume Control Adjust the sound level.

  • Page 42: Date Time Panel

    Intelligent Surveillance Solution 2. Playback 2.5.1 Date Time Panel 2.5.2 Record Display Window The record display window shows the information of the available video clips. It may show in calendar or list control view. For further details about how to modify the record display window view, see page 56.

  • Page 43: Date Time Period

    IP CamSecure 2. PlayBack Previous Days: To show recorded of previous recording date Next Days: To show recorded of next recording date 2.5.3 Date Time Period Select the start and end time points that indicate the time period you would like to view.

  • Page 44: To Withdraw The Record

    Intelligent Surveillance Solution 2. Playback To pressure the button “Show Event Log” makes Time Table show the time of event detection like below: Show Event Log 2.5.7 To Withdraw the Record Step 1: From the record display window at the top left of the Date Time Panel, select the date you want to withdraw the record from.

  • Page 45: Search Mode

    IP CamSecure 2. PlayBack Step 4: Check the Enable Preview option to get the preview of the video you select. Step 5: Click the camera name to increase or decrease cameras you want to playback. Step 6: Click OK when completing the setting.

  • Page 46: Unusual Event-Foreign Object

    Intelligent Surveillance Solution 2. Playback Interval: Move the slider control to the right to increase time interval so that the alarm will only be triggered when the movement lasts longer. Move to the left to reduce the time interval. Check the option to have the video stopped Stop When Found: when detecting motion in the detection zone.

  • Page 47: Unusual Event-Missing Object

    Move to the left to reduce the time interval. *IP CamSecure Lite32 only has General Motion option in Search Mode. 2.6.4 Unusual Event- Focus Lost / Camera Occlusion Focus Lost: System will inform you when the camera(s) lose its focus.

  • Page 48: Save Video

    Intelligent Surveillance Solution 2. Playback Sharpen: Check the option to activate the function. Move the slider control to the right to sharpen the image, to the left to soften it. Brightness: Check the option to activate the function. Move the slider control to the right to make the image brighter.

  • Page 49: Save Image

    IP CamSecure 2. PlayBack 2.9 Save Image Step 1: Click on the display screen to choose the camera display from which you want to save pictures. Step 2: Click Save Image button when the image you want is shown on the screen.
  • Page 50 Intelligent Surveillance Solution 2. Playback You can start a full function Playback Console and load the backup files into it on any PC with Windows operating system. This means you may monitor the real time video and work on the backup files on separate computers simultaneously.

  • Page 51: Log Viewer

    IP CamSecure 2. PlayBack 2.12 Log Viewer *IP CamSecure Lite32 only has System Log option in Log Viewer. 2.12.1 Unusual Event View the unusual event history that had been detected by the Smart Guard System. Step1 Step2 Step 4 Step 3 Step1: Choose the type of events you wish to view or select “All”...

  • Page 52: System Log

    Intelligent Surveillance Solution 2. Playback 2.12.2 System Log Select Log Type form the drop-down menu. There are total 31 types of log types, including: Main Console Startup 16. Stop Live Streaming Server Main Console Shutdown 17. Modify Live Streaming Server User Login 18.

  • Page 53: Counting Application

    IP CamSecure 2. PlayBack 2.12.3 Counting Application Display the history of Counting Application during a given time period. Step 4 Step1: Select the channel you want to check or select “All” from the drop-down menu for all channels. Step 2: Select search period.

  • Page 54: Pos Log

    Intelligent Surveillance Solution 2. Playback Step1: Select the channel you want to check or select “All” from the drop-down menu for all channels. Step 2: From the drop-down menu, set up how you would like the diagram to be displayed. You have the options of one day, one month, or one year.

  • Page 55: Export

    IP CamSecure 2. PlayBack Step 4: Click Search. Step 5: Press the button “Export to”. Step 6: Type the file name and choose the file format (.xls or .txt). 2.12.6 Export After search the log you want, just export it to .xls or .txt file.

  • Page 56: Setting

    Intelligent Surveillance Solution 2. Playback 2.13 Setting 2.13.1 Record Display Make the record Calendar View: display windows as calendar view. List Control: Make the record display windows as list control. 2.13.2 Play Play when open: Check the option and set the system to start playing the video clip every time when a record is withdrew.

  • Page 57: Miscellaneous

    IP CamSecure 2. PlayBack Automatically save the image file: By pre-setting a path/URL and the image format, the system will automatically save the image accordingly when you click the Save button in the control panel. 2.13.4 Miscellaneous Synchronize video frames:...

  • Page 58: Remote Server

    IP CamSecure 2. PlayBack 2.14 Remote Server 2.14.1 Add Remote Playback Site Press the “Remote Sever ” can go to remote playback site management to add and setup the remote playback site. Step 1: Enter the IP address or DNS, Port, Username, and Password.

  • Page 59: Schedule

    IP CamSecure 3. Schedule 3. Schedule Click on the Schedule icon on the Main Console and set up the time duration for video recording on the schedule configuration panel.

  • Page 60: Day Mode

    IP CamSecure 3. Schedule 3.1 Day Mode Schedule the cameras to turn the recorder on and off at the same time every day according to your setting. Load Camera / Channel Day Mode To setup the time schedule for each camera, you may 1.
  • Page 61 IP CamSecure 3. Schedule config/setting/camera/camera Parameter panel. FCS-8005 / FCS-8006 series (Analog camera) Mode Format Time Record Quality Resolution Regular MPEG-4 0:00-24:00 Always Normal Office MPEG-4 8:00-20:00 Always Normal Shop MPEG-4 10:00-22:00 Always Normal Highly Secure MPEG-4 0:00-24:00 Always Highest...

  • Page 62: Insert A New Schedule Manually

    IP CamSecure 3. Schedule 3.1.2 Insert a New Schedule Manually Step 1: Left-click and draw the bar you want add to the time table. The scheduled time will show as a grey bar. Step 1 Step 2 Step 3 Step 4...

  • Page 63: Week Mode

    IP CamSecure 3. Schedule 3.2 Week Mode Schedule the cameras for each day of the week differently. In addition, you may assign extra holidays under the Week Mode. Custom Holiday Default Week Mode 3.2.1 Default Follow the same process to setup the schedule for every day in a week.

  • Page 64: Adjust The Scheduled Setting

    IP CamSecure 3. Schedule 3.3 Adjust the Scheduled Setting: You can manually change the setting at any time after you insert or load a period of schedule. Option 1: Move the cursor to the Time Bar and change the length or move the bar sideway to change the start and end points.

  • Page 65: Encoding Option

    The maximum of pre-record/post record period is 60 seconds. 3.4.2 Record Mode Always Record: Select this option to record the video continuously. Record on Event: Select this option to obtain the Select Event panel . *Smart Guard is only in IP CamSecure Pro/Pro Plus/Pro Mega.

  • Page 66: Encoded Options

    IP CamSecure 3. Schedule From the Smart Guard list, check the box of the camera events or digital inputs to trigger the recording action. Click OK to complete the setting. Note: A prerequisite to trigger the recording schedule of camera/DI/POS event is to enable Smart Guard function in MainConsole start panel first.
  • Page 67 IP CamSecure 3. Schedule re-encoded by configuration. Click Setup button to adjust Encoder parameter. Note: There is only one adjustable option of Quality and Bit rate at one time. Customized encoding function will lead into high CPU usage, please make sure the PC specification is enough (recommend...

  • Page 68: Guard

    IP CamSecure 4. Guard 4. Guard *Guard is only in IP CamSecure Pro/Pro Plus/Pro Mega. Click on the Guard button on the Main Console to start the Event and Action Configuration panel. You need to specify an event to be detected as well as to set up an action with which the system will take when the specified event is detected.

  • Page 69: Event

    IP CamSecure 4. Guard 4.1 Event Insert Event There are 4 sources of events: Camera (video image), POS, Digital Input (device connected to your PC) and System (condition of your hardware). You can assign multiple events by following the instructions below.

  • Page 70: Camera Event - Signal Lost

    IP CamSecure 4. Guard Enable Event: Check the box to activate the event. Life Cycle: Automatically cancel event when event disappears: alarm/action will be cancelled once the abnormality is fixed or ends. Manually cancel event or event continues triggered: alarm/action will continue until being canceled from the Main Console.

  • Page 71: Camera Event - Foreign Object

    IP CamSecure 4. Guard sensitivity so that a relatively small movement will trigger the alarm. Move the bar to the left to reduce the sensitivity of movement detection. Set up an appropriate Sensitivity value will reduce the chance of false alarm. For example, you can lower the Sensitivity to avoid the alarm being triggered by a swinging tree in the breeze.

  • Page 72: Camera Event - Missing Object

    IP CamSecure 4. Guard Move the bar to the left to reduce the sensitivity of movement detection. Set up an appropriate Sensitivity value will reduce the chance of false alarm. For example, you can lower the Sensitivity to avoid the alarm being triggered by a swinging tree in the breeze.
  • Page 73 IP CamSecure 4. Guard Sensitivit Interval Region Definition Start Simulation Alarm Event Option: Sensitivity: Click and move the slider control to the right to increase sensitivity so that a relatively small movement will trigger the alarm. Move the bar to the left to reduce the sensitivity of movement detection.

  • Page 74: Camera Event - Lose Focus

    IP CamSecure 4. Guard Start Simulation: Click the Start Simulation button and test the function on the preview screen. 4.1.7 Camera Event - Lose Focus - This function alarms you when any of the cameras is losing focus and has blur image.

  • Page 75: Camera Event - Camera Occlusion

    IP CamSecure 4. Guard Interval: Click and move the slider control to the right to increase interval time so that the alarm will only be triggered when the movement lasts longer. Move to the left to reduce the interval time.

  • Page 76: Pos Event - Assign A Pos Event

    IP CamSecure 4. Guard movement lasts longer. Move to the left to reduce the interval time. Ignore Lighting: Check the box to avoid alarm being set off by light changing. Region Definition: Define detection zone: To detect General Motion, you have to define a detection zone.

  • Page 77: Digital Input Event - Digital Input Event

    IP CamSecure 4. Guard Step 3: Configure the setting of the Event Type. Please refer the User manual of POS for detail. 4.1.10 Digital Input Event - Digital Input Event Step 1 Step 2 Step 1: Click and highlight Digital Input on the event type list, and then click the Insert Event icon.

  • Page 78: System Event - Assign A System Event

    IP CamSecure 4. Guard 4.1.11 System Event - Assign a System Event Step 1 Step 2 Step 1: Click and highlight System on the event type list, and click the Insert Event icon. Step 2: There are Four events. Select the event you want to detect.

  • Page 79: System Event - Disk Space Exhausted

    IP CamSecure 4. Guard Activated Period: Always activated: Select the option to enable event when Main Console is running (Make sure the smart guard system is enabled in start panel). Activated only in the following period: You can set up the system to react during a certain time period;...

  • Page 80: System Event - Network

    IP CamSecure 4. Guard 4.1.16 System Event – Network Congestion - This function alarms you when network bandwidth is overloading. Current Status: Show you the current Total Upload Bitrate and Total Download Bitrate. Options: Check the High Upload Bitrate Alarm and High Download Bitrate...

  • Page 81: Action

    IP CamSecure 4. Guard 4.2 Action 4.2.1 Action - Assign a action type To setup actions responding to an unusual event. Insert Action: Step 1 Step 2 Step 1: Choose an event and click the “Insert Action” icon. Step 2: There are 10 types of actions, Select the action you want on list and then click OK.

  • Page 82: Action Type - On Screen Display

    IP CamSecure 4. Guard 4.2.2 Action Type - On Screen display - A red warning will be flashing on the screen of Main Console, indicating which type of unusual event is detected. Step 1: Select the “On Screen display” action and then click OK.

  • Page 83: Action Type - Send E-Mail

    IP CamSecure 4. Guard 4.2.4 Action Type - Send E-mail - The system will send an E-mail immediately to given accounts indicating the type of event, the time, and attaching a picture taken while the event is detected. Step 1: Select the “Send E-mail”...

  • Page 84: Action Type - Phone Call

    IP CamSecure 4. Guard 4.2.5 Action Type - Phone Call - The system will call a given phone number when an unusual event is detected. Step 1: Select the “Phone Call” action and then click OK. Step 2: The responding window will popup to Select Contactor (You can choose only one contact at once).

  • Page 85: Action Type - Di/Do

    IP CamSecure 4. Guard 3. Select the Life Cycle. 4. Click on Add. Set the action of camera 2: Choose camera 2. Set the start patrol and end patrol. Select the Life cycle Click on Add. Finally click on Ok to save all setting of cameras.

  • Page 86: Action Type -Send A Sms Message

    IP CamSecure 4. Guard 4.2.8 Action Type –Send a SMS message - The system will send a SMS message immediately to given accounts indicating the type of event, the time. Step 1: Select the “Send a SMS message” action and then click OK.

  • Page 87: Action Type - Popup E-Map On Event

    IP CamSecure 4. Guard 4.2.11 Action Type – Popup E-Map on Event - The system will auto popup E-Map window and show the assigned map and indicator. Step 1: Select the “Popup E-Map on Event” action and then click OK.

  • Page 88: Configuration

    IP CamSecure 5. Configuration 5. Configuration Config Click on the Config icon, select from the drop-down menu and open the Configuration panel. Modify the setting and access License Manager, Counting application, POS application, Log viewer, Backup, Network Services. Select Save/Load Configuration to save/load all the settings.

  • Page 89: Setting - General

    IP CamSecure 5. Configuration 5.1 Setting – General Storage Status Display Startup Miscellaneous 5.1.1 Startup Audio Preview Auto Reboot Check the MainConsole box to execute Main Console system when windows startup. Check the following 3 main functions and 5 network services to auto...

  • Page 90: Storage

    IP CamSecure 5. Configuration 5.1.2 Storage Location: Assign the default folder (you can setup several directories for storage) for the system to store all data files. Recommend not to save in system HD (C:\) to avoid PC efficiency drop when free storage is low.

  • Page 91: Status Display

    IP CamSecure 5. Configuration 4. POS Transaction: Delete the POS transaction data that is older than the number of days set. 5. Resource Report: Delete the Resource report data that is older than the number of days set. 5.1.3 Status Display Check the boxes of the information that you wish to see in the information display window in the Main Console.

  • Page 92: Audio Preview

    DDNS function by selecting the provider type, filling with user name, password and hostname, and adjusting the update period. *DDNS Service is only in IP CamSecure Pro/Pro Plus/Pro Mega. 5.1.5 Audio Preview Default Channel: Select the audio channel that you wish to hear from in “Default Channel”.

  • Page 93: Auto Reboot

    IP CamSecure 5. Configuration System plays the audio of System plays the audio of left-top “default channel” “selected channel” 5.1.6 Auto Reboot Check the option of “ Enable Auto Reboot ” that you can reboot the system on the time you select.

  • Page 94: Setting - Camera

    IP CamSecure 5. Configuration 5.2 Setting - Camera Config Search Insert Con g Delete 5.2.1 Add Camera Four function buttons will be included in the Setting/Camera panel if you have our Hybrid Surveillance System license for IP camera. Search: Click on the Search icon to obtain the Search IP Camera panel.

  • Page 95: Ip Camera / Video Server Setting Panel

    IP CamSecure 5. Configuration Delete: Click on the Delete button to remove the selected IP camera(s) from the system. Click OK to finalize the modification. Config: Click on the Config button to obtain the IP/Video Server Setting panel. You can modify the IP camera settings with the Setting panel. See following part(IP Camera / Video Server Setting panel) for detail.

  • Page 96: Camera Parameter

    IP CamSecure 5. Configuration 5.2.3 Camera Parameter Camera List Camera Name Go to Web Interface Camera Settings Video Parameter Stream Profile Camera List: The camera(s) connected to the system will show on the panel, click the name of the camera to adjust the setting.
  • Page 97 IP CamSecure 5. Configuration Stream Profile Options Note: The types of stream profile and options will different with stream sources. IP camera: 5 profiles with Original (only can drop frame rate), High, Normal, Low and Minimum (for PDA/Smart Phone Client).

  • Page 98: Osd Setting

    IP CamSecure 5. Configuration 5.2.4 OSD Setting Select the information that you wish to see in the on-screen display, or the sub-screen of the camera. And then, click the Font button to setup the font style.

  • Page 99: Setting - I/O Device

    IP CamSecure 5. Configuration 5.3 Setting - I/O Device Device Setting I/O Device Setting List of devices Input Monitor Output Monitor I/O Device Setting: Module Setting: Name the module device and ID that has been connecting the digital input/output device(s) to your system.

  • Page 100: Setting - Ptz Config

    IP CamSecure 5. Configuration 5.4 Setting - PTZ Config Basic Setting Advanced Setting Miscellaneous Install PTZ cameras and follow the instruction of the camera manufacturers. A PTZ camera is usually connected to the PC with RS-485/RS-422. Check the box on the camera list to activate the PTZ control function of a PTZ camera.
  • Page 101 IP CamSecure 5. Configuration User-Define Preset: User-Define Preset for analog speed dome can trigger the extra-function of speed dome itself such as auto-tracking, login menu of camera…etc. You can refer the detail description of each analog speed dome on it’s user manual.

  • Page 102: Setting - Hotline

    IP CamSecure 5. Configuration 5.5 Setting – Hotline *Hotline is only in IP CamSecure Pro/Pro Plus/Pro Mega. Configure the settings of hotlines, including E-mail, FTP, GSM modem and Telephone calls, once an unusual event is detected. Input the following information: Server, Port, Sender’s E-mail E-mail: address, E-mail’s subject title, Body content and SSL option for encrypted...
  • Page 103 IP CamSecure 5. Configuration Note: 1. You must use a modem with voice capability. 2. You may select a Wave format file; it will be played in the phone to alarm the person who picks up the phone call. GSM modem: Set the Port and Baud Rate of the GSM modem device, and then enter PIN code.

  • Page 104: Setting - Address Book

    IP CamSecure 5. Configuration 5.6 Setting - Address Book *Address Book is only in IP CamSecure Pro/Pro Plus/Pro Mega. Address Book: Manage the address book from which you may send out a phone call or an E-mail when an unusual event is detected.

  • Page 105: Setting - Monitor Display

    Activate auto scan to rotate the channels/ cameras on the Auto Scan: display screen. *The dual monitor is only in IP CamSecure Pro/Pro Plus/Pro Mega. For instance, you may select to show only 4 sub-screens on the main console while having 16 channels connected to the system. With auto scan function, you will be able to see all 16 channels by turns.

  • Page 106: Setting - Joystick

    IP CamSecure 5. Configuration 5.8 Setting – Joystick Function Parameter Import Export Default Function: You can choose the function from the drop-down menu for the button of joystick.
  • Page 107 IP CamSecure 5. Configuration Following is a complete list of all log types: Note: 9. Start/Stop Auto Scan Goto Preset Point 10. PTZ Speed Up Goto Camera 11. PTZ Speed Down Goto Previous Camera 12. Zoom Wide Goto Next Camera Switch 13.

  • Page 108: User Account Setting

    IP CamSecure 5. Configuration 5.9 User Account Setting Only default admin account could manage the user accounts here. From the list on this tab, highlight each account and modify the privilege setting. There are 3 default privilege profiles of account groups:...
  • Page 109 IP CamSecure 5. Configuration Note: The “Add” button is only enabled when filled a new account. Delete: Click it to delete the indicated account. Default: Click it to go back to default privilege settings of related user group. Upgrade: Click it to save the modifications of each account.

  • Page 110: License Manager

    IP CamSecure 5. Configuration 5.10 License Manager The license of the software should be registered first before operating the former version of Intelligent Surveillance System. Execute the License Management Tool in Config >License Manager to activate the license from dongle or serial number allocated with the software package, or de-activate the license then bring it to another PC to activate it again.

  • Page 111: Save/ Load Configuration

    IP CamSecure 5. Configuration 5.11 Save/ Load Configuration The Save/ Load Configuration function allows system users to save any specific setting as a cfg (config) file. You may save up several different cfg files at any time. Save Configuration: To save a specific setting, go to Config > Save/ Load Configuration >...

  • Page 112: Counting Application

    Step 2 Step 3 Start Simulation Options Runtime *Counting Application is only in IP CamSecure Pro/Pro Plus/Pro Mega. Step 1: Check the box of the camera to apply the Counting Application to it. Step 2: In Operation section, check the option “Define detection zones”...

  • Page 113: Pos Application

    IP CamSecure 5. Configuration 5.13 POS Application Each Main Console system can manage up to 64 POS cash register devices. The POS Application tool is help to configuration POS devices, please refer the User manual of POS for detail.

  • Page 114: Network Service

    Main Console, go to Config > Network Service to obtain the Network Service panel. *IP CamSecure Lite32 only has Live Streaming and Remote Playback in Network Service. 5.14.1 Live Streaming Server When starting the live streaming function of computer, the system allows remote users to log in to the specific computer and view cameras that are connected to it.
  • Page 115 IP CamSecure 5. Configuration Kill Client: Highlight an IP address and click on the “Kill Client” button to block the client from your client list. Kill All Clients: Click on this button, and then block all the clients logging to your system.
  • Page 116 IP CamSecure 5. Configuration White List: Check the “Enable White List” box to activate the white list filter. Only IP from the white list is allowed to log in. Black List: Check the “Enable Black List” box to activate the black list filter.

  • Page 117: Remote Playback Server

    IP CamSecure 5. Configuration 5.14.2 Remote Playback Server *There is only 1 channel displayed in Remote Playback in IP CamSecure Lite32 while there are up to 16 channels displayed in IP CamSecure Pro/Pro Plus/Pro Mega simultaneously. When starting the remote playback function, the system allows remote users to log in to the specific computer and withdraw data files that are stored on it.
  • Page 118 IP CamSecure 5. Configuration Options: Adjust the setting only when the server is stopped. Port: Assign a port for the clients to connect to your system via Remote playback server. Default port is 5160. Maximum Users: Number of connections that are allowed to connect to the system.
  • Page 119 IP CamSecure 5. Configuration server and remote playback server. Performance Total bit rate Individual Camera bit rate information Remote playback Server log information...

  • Page 120: 3Gpp Service

    IP CamSecure 5. Configuration 5.14.3 3GPP Service When starting the 3GPP service function of your computer, the system allows remote users to log in and view cameras that are connecting to it with 3GPP supported mobile phone. See Appendix A for more details about 3GPP Service.

  • Page 121: Remote Desktop

    B to install and use this tool. Option Authentication Server Status *Remote Desktop is only in IP CamSecure Pro/Pro Plus/Pro Mega and there are up to 16 channels displayed simultaneously. Options: Port: Assign a port for Desktop tool to login and configure system.

  • Page 122: Central Management Service

    Console would send event information to NCS and allow NCS system to control I/O device from remote side. *CMS is only supported in IP CamSecure Pro/Pro Plus/Pro Mega. Note: 1. To enable this action, go Guard >Action and select “Send to Central Server”...
  • Page 123 IP CamSecure 5. Configuration Port: Assign a port for NCS System to connect Main Console system. Default port is 5170. Maximum Connections: Number of connections from NCS Servers that are allowed to connect to the system. The default is 8 NCS Servers...

  • Page 124: About Main Console

    IP CamSecure 5. Configuration 5.15 About Main Console Go to About Main Console to view the version of your surveillance system and the hardware information. 5.16 Video Source (For system with MPEG4 capture device only) Step 1: Go to Video Source to adjust the Video Standard to NTSC or PAL.

  • Page 125: E-Map

    IP CamSecure 6. E-Map 6. E-Map With E-Map, user can find out or track the actual location and alarm status easily and receive instant response when the event happens. The arrows and lightening icon on E-Map represent cameras and I/O devices and these icons will turn red once they are triggered by alarms.

  • Page 126: Edit Mode

    IP CamSecure 6. E-Map There are 2 modes in E-Map application: Edit mode: Allow users to add/edit maps and indicators of devices. In Edit mode, the function buttons on the bottom of the window will be active, and then setup the configuration before running E-map function at the first time.

  • Page 127: Add/Rotate/Delete Device Indicator

    IP CamSecure 6. E-Map Step 3: Select the map file and insert the map name. Click “OK”, and then the map you added appears in the tree structure of device and map list. Step 4: The map indicator appears on the left-up corner of parent map.
  • Page 128 IP CamSecure 6. E-Map Step 2: Select on the icon “ Map ” which you want add device indicator Step 3: Before adding indicator, ensure that the map you want is displayed. Select device from list and directly drag a device to the desired location on the map.

  • Page 129: Operate Mode

    IP CamSecure 6. E-Map 6.2 Operate Mode To carry out the operation functions in E-Map, you need to be in Operate Mode. Operate mode/ Edit mode Switch button 6.2.1 Device and Map Tree list This window will list all devices and map hierarchies; click device or map indicator to show related information on E-Map windows.

  • Page 130: E-Map Picture

    IP CamSecure 6. E-Map 6.2.2 E-Map picture This window will show the map layer and indicators. Device Indicator: Select device indicator form Device and Map Tree list to show preview video and related information. Map indicator: Select map indicator will enter the next map layer. If you want move to...

  • Page 131: Layout Adjustment

    IP CamSecure 6. E-Map Triangular 6.3 Layout Adjustment indicator 6.3.1 Adjust layout window Shrink the window: Click “ Triangular indicator” to hide the Device and Map/ Preview and Information window on right and left side. click triangular indicator again to go back to default setting.

  • Page 132: Log Viewer

    IP CamSecure 7. Log Viewer 7. Log Viewer View the unusual event history that had been detected by the Smart Guard System. To launch Log Viewer and get report, simply click on Config and select Log Viewer from menu to open Log Viewer window...

  • Page 133: Unusual Event

    IP CamSecure 7. Log Viewer 7.1 Unusual Event Step1 Step2 Step 4 Step3 Step1: Choose the type of events you wish to view or select “All” from the drop-down menu to view all types of events. The types of Unusual Event...

  • Page 134: System Log

    IP CamSecure 7. Log Viewer 7.2 System Log Select Log Type form the drop-down menu. There are total 31 types of log types, including: Main Console Startup 16. Stop Live Streaming Server Main Console Shutdown 17. Modify Live Streaming Server User Login 18.

  • Page 135: Counting Application

    IP CamSecure 7. Log Viewer 7.3 Counting Application Display the history of Counting Application during a given time period. Step 4 Step1: Select the channel you want to check or select “All” from the drop-down menu for all channels. Step 2: Select search period.

  • Page 136: Counting Application (Diagram)

    IP CamSecure 7. Log Viewer 7.4 Counting Application (Diagram) Display the Counting Application data in diagram format. Step 4 Step1: Select the channel you want to check or select “All” from the drop-down menu for all channels. Step 2: From the drop-down menu, set up how you would like the diagram to be displayed.

  • Page 137: Pos Log

    IP CamSecure 7. Log Viewer 7.5 POS Log View the POS Log history that had been detected by the Smart Guard System. Step 5 Step1: Choose the type of events you wish to view or select “All” from the drop-down menu to view all types of events. The types of Unusual Event include Transaction Start, Transaction End, Open Cash Register, Connection Lost, and special User defined event.

  • Page 138: Export

    IP CamSecure 7. Log Viewer 7.6 Export After search the log you want, just export it to .xls or .txt file. Step 1 Step1: Press the button “Export to”. Step2: Type the file name and choose the file format (.xls or .txt).

  • Page 139: Backup

    IP CamSecure 8. Backup 8. Backup The backup function saves video record and other log information. User may open backup files on any PC with Windows Operation System and operate the full function Playback panel on it. Follow the instructions below to obtain backup files.

  • Page 140: Backup Recorded File(S)

    IP CamSecure 8. Backup 8.1 Backup Recorded file(s) Step 1 Step 2 Step 3 Step 1: Add (Remote) Backup Site : Press the “Remote Sever ” can go to remote backup site management to add and setup the backup site.
  • Page 141 IP CamSecure 8. Backup Step 6 Step 4 Step 5 Step 5: Click on the camera number icon to add camera(s) Step 7 or click to add/delete all the channels. Step 6: Check the box of Enable Preview to get the preview of the video you select.

  • Page 142: Delete Recorded File(S)

    IP CamSecure 8. Backup Step 9: Click the Backup icon to obtain Backup panel. Step 10 Step 11 Step 12 Step 10: Summary: Check the summary section to see the size of the file(s). Step 11: Media: Choose the path you want to save the file or burn the file into a CD (direct CD burning for Windows XP only), DVD or on Hard Disk.
  • Page 143 IP CamSecure 8. Backup Step 2: Follow step 3-7 on above (backup) section to select data period which you want to delete. Step 3: Click on the “Delete” icon and delete all the data in the backup list from the database.

  • Page 144: Remote Live Viewer

    With the Remote Live Viewer console, remote users may watch up to 128 channels real-time video from remote live streaming servers. *There is only 1 channel displayed in Live Viewer in IP CamSecure Lite32 while there are up to 16 channels displayed in IP CamSecure Pro/Pro Plus/Pro Mega simultaneously.

  • Page 145: Setting

    IP CamSecure 9. Remote Live Viewer 9.1 Setting Click General Setting to obtain setting dialog. General Setting 9.1.1 General Setting Audio preview: Enable audio on active channel: Select it to enable the audio streaming on active channel. Miscellaneous: Synchronize video frames: Select it to avoid the tearing problem occurring in video display while increasing the CPU loading.

  • Page 146: Server Setting

    IP CamSecure 9. Remote Live Viewer 9.1.2 Server setting Server List Step 1: Enter the Server Name as preference. Step 2: Enter the Address, Port, User Name, Password to log in the server. Step 3: Enable the Save Password to login without entering the password again.

  • Page 147: Group Setting

    IP CamSecure 9. Remote Live Viewer 9.1.3 Group Setting Allocate different cameras into each appointed group. Step 1 Step 2 Step 4 Step 3 Step 1: Log in to all the servers that contain the camera(s) you would like to put into the group(s).

  • Page 148: Camera Setting

    IP CamSecure 9. Remote Live Viewer 9.1.4 Camera Setting Select prefer stream type of each camera as default live view profile. Stream Profile Info: Stream profile: The list would different with video input type of server Auto: The system will adjust the stream type automatically to fit different screen division.

  • Page 149: Osd Setting

    IP CamSecure 9. Remote Live Viewer 9.1.5 OSD Setting Adjust font style of Camera OSD on this panel. 9.1.6 POS Setting Adjust font style of POS overlay on this panel.

  • Page 150: Monitor Display Setting

    IP CamSecure 9. Remote Live Viewer 9.1.7 Monitor Display Setting Activate auto scan to rotate the channels/ cameras on screen. Note: 1. For instance, you may select to show only 4 sub-screens on the live viewer while having 16 channels connected to the system. With auto scan function, you will be able to see all 16 channels by turns.

  • Page 151: Notification Setting

    IP CamSecure 9. Remote Live Viewer Step 5: Layout: Select the screen division of “NxN type”in Remote live viewer panel. 9.1.8 Notification Setting Status display: Show recording status: Select it to show the indicator with recording status on monitor display.

  • Page 152: Joystick Setting

    IP CamSecure 9. Remote Live Viewer 9.1.9 Joystick Setting Please switch to Joystick tab and the configuration is the same as on Main console, please refer page 106 for details.

  • Page 153: Server/Group/Camera

    IP CamSecure 9. Remote Live Viewer 9.2 Server/Group/Camera Display a complete list of the server(s),group(s) and camera(s) that are added to the system. Server View: The cameras would list beyond associated server. Group View: The cameras would list beyond customized grouping.

  • Page 154: Multiple View

    IP CamSecure 9. Remote Live Viewer Option4: Play / Stop/ Drop: Select a camera/ video and click on this button to play/stop/disconnect a particular channel. Play Drop Stop 9.2.3 Multiple View: Step1: On the server/ camera list, select a camera and right click on it to obtain the menu options.

  • Page 155: Ptz Control

    IP CamSecure 9. Remote Live Viewer 9.3 PTZ Control Control the movement of PTZ cameras. With cameras that support PTZ control, you can move, zoom, patrol, adjust the focus, and set preset points of the cameras. 9.3.1 Preset/ Go Adjust the camera view until satisfied. Click on the Set icon and set up the view as the preset point 01.

  • Page 156: On Screen Menu

    IP CamSecure 9. Remote Live Viewer 9.4 On Screen Menu Right click on the camera screen and get the “On Screen Menu”, from which you can quickly adjust the setting of camera. 9.4.1 Enable Move With cameras that support PTZ function, the function allows to use mouse to control PTZ function by clicking display screen.

  • Page 157: Start Monitor

    IP CamSecure 9. Remote Live Viewer 9.5 Start Monitor Start Monitor 9.5.1 Multiple Monitor Select open monitor to append monitor to view more live videos on multiple monitors. Each append monitor has the same list and view control buttons with Main monitor, except Start, Playback, and Setting buttons.

  • Page 158: Playback

    IP CamSecure 9. Remote Live Viewer 9.6 Playback Select it to obtain the Playback panel and view video remotely. 9.6.1 Add Remote Playback Site Press the “Remote Sever ” can go to remote playback site management to add and setup the remote playback site.

  • Page 159: Web View

    Must make sure the Liver Stream Server is enabled. Check 5.14 Network Service for more detail. *There is only 1 channel displayed in Live Viewer via web browser in IP CamSecure Lite32 while there are up to 4 channels displayed in IP CamSecure Pro/Pro Plus/Pro Mega simultaneously. page-159...

  • Page 160: Server Ip

    IP CamSecure 10.WebView 10.1 Server IP Open an Internet Explorer browser and enter the IP address or DDNS “name” of the server followed by the connecting port. Example: http://192.168.1.16:8080/ Note: 192.168.1.16 is the IP address of the server. 8080 is the port specified in “Use Default Web Server” in Network Service.

  • Page 161: Utilities

    IP CamSecure 11.Utilities 11. Utilities Verification Tool License Management Tool Resource Management Tool DB Tool page-161...

  • Page 162: Verification Tool

    IP CamSecure A. Verification Tool A. Verification Tool The Verification Tool verifies whether the data created by the system be tampered with or not. It is the process by which a digital watermark (a digital signature) is added to each recorded video frame to ensure its authenticity.

  • Page 163: Verification Tool Overview

    IP CamSecure A. Verification Tool 1.2 Verification Tool Overview Add File Add Folder Remove File Video Preview Select All Play Verify Pause Stop Add File: Click it to insert the single file to list for verification. Add Folder: Click it to choose the folder with multiple files to list for verification.

  • Page 164: Verify Image/Video

    IP CamSecure A. Verification Tool 1.3 Verify Image/Video Step 1: Select single or multiple files for verification. Step 2: Click “verify ”to start verification. Step 3: The verification result will show on watermark column. If a file was tampered with, it will show...

  • Page 165: License Management Tool

    IP CamSecure B. License Management Tool B. License Management Tool The license of the software should be registered first before operating the former version of Intelligent Surveillance System. Execute the License Management Tool to activate the license from dongle or serial number allocated with the software package, or de-activate the license then bring it to another PC to activate it again.

  • Page 166: License Management Tool Overview

    IP CamSecure C. Resource Management Too 1.1 License Management Tool Overview 1.1.1 Execute License Management Tool Step 1: Execute “License Manager” Tool in config menu or installation folders. Step 2: The “License Management Tool” will appear. Please refer below for the tool overview.
  • Page 167 IP CamSecure B. License Management Tool Transfer Transfer Tab SN status Transfer type Transfer...

  • Page 168: Activate/Transfer License

    IP CamSecure C. Resource Management Too 1.2 Activate/Transfer License 1.2.1 Activate License Activation Online Step 1: Open “License Manager” Tool. Step 2: Select “On line” as Activate type. Step 3: Input the “SN (Serial number)”or “Import SN file”, and then click on “Activate”...
  • Page 169 IP CamSecure B. License Management Tool Step 4: Save “Request file” , and then take it to another PC connected to Internet. Step 5: Execute “ OffLineTool.exe ” in another PC , and then click “Activate” to send request file to license server.
  • Page 170 IP CamSecure C. Resource Management Too 1.2.2 Transfer License Transfer On line Step 1: Open “License Manager” Tool. Step 2: Select “Transfer” Tab, and then check “On line” as Transfer type. Step 3: Select “SN" and click on “Transfer” button.
  • Page 171 IP CamSecure B. License Management Tool Step 4: Save “Request file”. Restart MainConsole if activated successfully. Step 5: Copy request file to another PC connected to internet. Step 6: Execute OffLineTool.exe in another PC, check Transfer SN and click “Transfer” to send request file to license server.

  • Page 172: Resource Management Tool

    IP CamSecure C. Resource Management Tool C. Resource Management Tool The Resource Management Tool could detect whether the system operation is normal or not. Note: For further application of Resource Management Tool, please refer page 68 In “Guard” chapter. 1.1 Execute Resource Management tool Step 1: Open Resource Report from start menu.
  • Page 173 IP CamSecure C. Resource Management Tool 1.2.1 System Resource System Health: This item shows the system information, including “CPU Temperature”, “Motherboard Temperature”, “CPU Fan Speed” and “Power Fan Speed”. Note: User needs to install the “SpeedFan” first to gather the CPU and Motherboard temperature information.

  • Page 174: Advanced Resource Report

    IP CamSecure C. Resource Management Too 1.3 Advanced Resource Report Click “Advanced button to search and export system logs in “Search” tab and obtain the history diagram of an specified period in “Diagram” tab. 1.3.1 Search Step 4 Step 3...
  • Page 175 IP CamSecure C. Resource Management Tool 1.3.2 Display Step 4 Step 5 Step 1 Step 2 Step 3 Step 6 Step 1: Choose the system event type. Step 2: Select the DateTime to draft history diagram. Step 3: Setup the start time and duration for charting. User can choose “One Day”, “One Hour”...

  • Page 176: Db Tool

    IP CamSecure D. DB Tool D. DB Tool The DB Tool Repair database files and Export configurations. Warning : improper use of this DB Tool may cause lose of the recorded video data. Step 1: Execute DB Tool from program files.

  • Page 177: Repair Database

    IP CamSecure D. DB Tool 1.1 Repair Database This page has three repair method, Modify Location, Verify Only, and Repair. For modify location propose: Playback system can recognize all recording video in the folders which list on MainConsole > Config > Setting > General page. For some reason, user need use Playback system to open recording video beyond storage location setting.
  • Page 178 IP CamSecure D. DB Tool Step 4: Click on Modify button to modify location. After modification, the Modify Result will show on the panel. Example of modify database: In certain case that when video data needs to be transfer from old PC to another new PC, user will need to perform the following procedure.
  • Page 179 IP CamSecure D. DB Tool Step 1: Switch to Repair database windows. Step 2: Select the repair Method as Modify Location. Step 3: Check the video location windows. The system will list all video locations in table, but if there are any omit, please use to insert.
  • Page 180 IP CamSecure D. DB Tool Note: Open Log is a tool to record repair database recode. It will recode repair method, file operation, strat time and end time.

  • Page 181: Export Configurations

    IP CamSecure D. DB Tool 1.2 Export Configurations This tool is using when user want to export all configuration to backup, take to another PC for backup. Step 1: Press “Export”. Step 2: Select the location you want to Export and type the name of the configurations.

  • Page 182: Appendix A - 3Gpp Service

    IP CamSecure Appendix A Appendix A - 3GPP Service How to setup 3GPP streaming connection (using BenQ-Siemens mobile phones) System Configuration DVR / NVR server v2.6 CPU: Intel core2 Duo 1.86 GHz Memory: 512 DDR RAM Ethernet: Realtek RTL8168/8111 PCI-E...

  • Page 183: Configuration From 3G Mobile Phone

    IP CamSecure Appendix A Step 2 : Select 3GPP Service, and then click Start Note: In the Option item, the “port” selected here is the same port from mobile handset 1.2 Configuration from 3G Mobile Phone 1.2.1 BenQ-Siemens E81 Step 1:...
  • Page 184 IP CamSecure Appendix A Step 2: Select Bookmarks Step 3: Add New Bookmark Step 4: Configure the Adress setting as the following example. Ex: rtsp://61.216.97.69:554/media00.3gp 61.216.97.69:554 is the IP address of NVR or DVR system port specified in 3GPP Service from NVR or DVR system...
  • Page 185 IP CamSecure Appendix A Step 5: Save the settings and start playing...

  • Page 186: Benq P50

    IP CamSecure Appendix A 1.2.2 BenQ P50 1. Connect GPRS 2. Download and install the [PLATFORM4] software. 3. Execute Main Console.
  • Page 187 IP CamSecure Appendix A 4. Press the [Config] [Network Service] [Start] 5. Open [PLATFORM4], press the button framed by red into Option...
  • Page 188 IP CamSecure Appendix A 6. [Open Url] enter the rtsp address of the camera (EX: rtsp://61.216.97.69/media00.3gp channel 1 EX: rtsp://61.216.97.69/media01.3gp channel 2 EX: rtsp://61.216.97.69/media02.3gp channel 3) 7. [Setting I]change the setting and press “OK” [Protocol] [Buffer Size] [Connection TimeOut] [Data Recept. TimeOut]...
  • Page 189 IP CamSecure Appendix A 8. Go back to PLATFORM4, searching and then getting the video...

  • Page 190: Appendix B - Pda / Smart Phone Client

    IP CamSecure Appendix B Appendix B – PDA / Smart Phone Client PDA / SP (Smart Phone) Client are only applied for devices with Windows Mobile 5.0 platform or above. See the sections below to find how to install and execute PDA / SP Client.

  • Page 191: Execute And Login

    IP CamSecure Appendix B Step 2: Select “Live Streaming”, and then click “Start”. Note: The “Port” selected here will be the same with the one in PDA/Smart Phone. Live Streaming Start Port 1.2.2 Execute and Login Step 1: Check your PDA/Smart Phone device is connected to network, and then go to Start >...

  • Page 192: Pda/Smart Phone Client Overview

    IP CamSecure Appendix B 1.3 PDA/Smart Phone Client Overview There are 3 main pages of Client application: Monitor Preview, I/O Control and System Info. Switch between these buttons to adjust overall configurations. Log out System Info Live View I/O control 1.3.1 Live View...

  • Page 193: I/O Control

    IP CamSecure Appendix B Live Video Display: Live View panel could display “live video”, control PTZ, and snapshot. Click to go back camera list. PTZ Control: Click on PT Control Panel and Zoom Out/In to control physical PTZ camera or adjust digital PTZ under digital PTZ mode.

  • Page 194: System Info

    IP CamSecure Appendix B I/O Device DI/DO I/O Device list : Select and monitor the device connected with Server. DI/DO status : Monitor the DI/DO status synchronized with Server, and then click Output button to trigger the DO action. Gray icon indicates the normal status of DI/DO devices.

  • Page 195: Appendix C - Remote Desktop Tool

    IP CamSecure Appendix C Appendix C - Remote Desktop Tool How to install Remote Desktop Tool Step 1: Insert the Installation CD. Step 2: Please go to RemoteDesktopViewer directly and Run Setup.exe file. How to Start Remote Desktop Tool Step 1: Please point to Start >...

Table of Contents
