LevelOne FCS-1010

P/T IP Camera

Quick Installation Guide

System Requirements

Windows 98, 98SE, Millennium Edition (ME), 2000 and XP operating systems

♦

PC with Pentium III 800MHz system or above is recommended

♦

Memory Size:128MB (256 is recommended)

♦

NOTE:

All the captured images of installation mentioned in this user's manual

were based on Windows XP operating system. For installation on other

Windows OS, e.g. Windows 98SE, all the procedures remains the same.

LevelOne FCS-1010 Hardware Installation

Connect the Ethernet Cable

Connect an Ethernet cable to the

Ethernet connector located on

the back panel of FCS-1010.And

attach it to the newwork

Please use a cross-over Ethernet cable if you connect this camera directly to a PC.

Need help?

Do you have a question about the FCS-1010 and is the answer not in the manual?

Questions and answers

Summary of Contents for LevelOne FCS-1010

Page 1: Quick Installation Guide
LevelOne FCS-1010 Hardware Installation Connect the Ethernet Cable Connect an Ethernet cable to the Ethernet connector located on the back panel of FCS-1010.And attach it to the newwork Please use a cross-over Ethernet cable if you connect this camera directly to a PC.
Page 2 Attach the AV cable(optional). Connect the AV cable only if you wish to connect FCS-1010 to a TV set. Attach the AV cable to the AV out connector . Attach the yellow RCA connector to the “Video” connector on your TV.
Page 3 Configuring your FCS-1010 with IP Installer Insert the FCS-1010 CD into the CD-ROM drive. Click on “IP Installer”. IP Installer screen shall show up. The IP Installer will show a MAC address and an IP Address of available FCS-1010.
Page 4 After successful linkage, the authentication window should pop up. The default user name is “root”. The default password is the MAC address of your own FCS-1010, which marks at the bottom label of each device. Please enter the MAC address in...
Page 5 Viewing Your LevelOne FCS-1010 The following screen would appear automatically after successful login. Click “Yes” and proceed. FCS-1010 should be active by now. It is highly recommended that set a password for security purposes. Click on Configuration for setting the password.
Page 6: Configuration Page
Configuration Page This is the page where you can change the basic settings of the FCS-1010. Click on “Security” and set your password and add additional accounts to the FCS-1010 necessary. The basic installation and configuration of FCS-1010, P/T IP Camera, is...
