4 . 1 . 3 M P o A
4 . 1 . 3 M P o A
MPoA is a specification that enables ATM services to be integrated with existing LANs,
which use either Ethernet, token-ring or TCP/IP protocols. The goal of MPoA is to allow
different LANs to send packets to each other via an ATM backbone.
To use MPoA as the accessing protocol of the Internet, select MPoA mode. The following
web page will appear.
Available settings are explained as follows:
Item
MPoA (RFC1483/2684)
DSL Modem Settings
Vigor2710 Series User's Guide
Description
Click Enable for activating this function. If you click
Disable, this function will be closed and all the settings that
you adjusted in this page will be invalid.
Set up the DSL parameters required by your ISP. These are
vital for building DSL connection to your ISP.
Multi-PVC channel - The selections displayed here are
determined by the page of Internet Access – Multi PVCs.
Select M-PVCs Channel means no selection will be chosen.
90
