Default Configuration - Analog Devices EZ-KIT Lite ADSP-21364 System Manual

• USB 2.0 cable
• Registration card (please fill out and return)
If any item is missing, contact the vendor where you purchased your
EZ-KIT Lite or contact Analog Devices, Inc.

Default Configuration

The EZ-KIT Lite evaluation system contains ESD
(electrostatic discharge) sensitive devices. Electrostatic
charges readily accumulate on the human body and
equipment and can discharge without detection. Per-
manent damage may occur on devices subjected to
high-energy discharges. Proper ESD precautions are
recommended to avoid performance degradation or
loss of functionality. Store unused EZ-KIT Lite boards
in the protective shipping package.
The ADSP-21364 EZ-KIT Lite board is designed to run outside your per-
sonal computer as a stand-alone unit. You do not have to open your
computer case.
When removing the EZ-KIT Lite board from the package, handle the
board carefully to avoid the discharge of static electricity, which may dam-
age some components.
To connect the EZ-KIT Lite board:
1. Remove the EZ-KIT Lite board from the package. Be careful when
handling the board to avoid the discharge of static electricity,
which may damage some components.
2. Figure 1-1
LEDs used in installation. Confirm that your board is set up in the
default configuration before continuing.
ADSP-21364 EZ-KIT Lite Evaluation System Manual
shows the default DIP switch, connector locations, and
Using ADSP-21364 EZ-KIT Lite
1-3
