• Analog audio interface

AD1835A codec

4x2 RCA phono jack for 4 channels of stereo output

2x1 RCA phono jack for 1 channel of stereo input

Headphone jack for 1 channel stereo output

• Digital audio interface

RCA phono jack output

RCA phono jack input

• LEDs

11 LEDs: 1 power (green), 1 board reset (red), 1 USB mon-

itor (amber), and 8 general purpose (amber)

• Push buttons

5 push buttons: 1 reset, 2 connected to DAI,

2 connected to the

• Expansion interface (type A)

Parallel port,

• Other features

JTAG ICE 14-pin header

0-ohm resistors for processor current measurement

SPI header

DAI header

The EZ-KIT Lite board has a total of 1 MB of parallel flash memory and

2 MB of SPI flash memory. The flash memories can store user-specific

boot code, allowing the board to run as a stand-alone unit. For more

ADSP-21364 EZ-KIT Lite Evaluation System Manual

pins of the processor

FLAG

s, DAI, SPI

FLAG
