ELECTRICAL PARTS REMOVAL/REPLACEMENT
Step 1:
Remove the console and lower/upper covers according to the "Lower/Upper Cover Removal" process.
Step 2:
The mid-step counter cable (#A5409)
is hidden within a frame channel on the
upper part of the main frame behind the
brake, carefully pull out the cable to
access the housing connection between the
mid-cable and the magnet cable (#A5410).
Step 3:
Disconnect the mid and magnet cables.
SCIFIT Scientific Solutions For Fitness
SPECIFICATIONS
SPECIFICATIONS
mAgnET cABLE rEmovAL
SCIFIT
Frame channel
Magnet Cable
Mid-Cable
