- Page 1 SCIFIT Service Manual 4000 Series Stepper SCIFIT Service Center 5616 A, S. 122 E. AVE. TULSA, OK 74146 800-745-1373 ext 21 scifit@busprod.com...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Replacement Parts List For Stepper ................3 Replacement Parts Drawing .................... 4 Parts Replacement Procedures For Stepper Brake ....................... Brake Power Adjustment .................. 5 Cable ....................... Fuse ......................... Lower Board Wiring Diagram ................7 Eprom Replacement ..................7 Troubleshooting Guide ..................... -
Page 3: Replacement Parts List For Stepper
REPLACEMENT PARTS LIST FOR STEPPER ITEM PART NUMBER PART DESCRIPTION 333944005 3” Cable Pulley 444SI-140 Speed Sensor Pickup 333947003 Extension Spring 222GS-33 Speed Pickup Decal 333940504 Left Drive Hub 333940505 Right Drive Hub 333944009 2” Square Plastic Cap 333944004 2” Aluminum Cable Pulley 333944015 2-1/2 Rubber Stop 333946008... -
Page 5: Brake Power Adjustment
4000 Series Stepper REMOVE STEPPER BRAKE 4000 SERIES 1. Remove hood. 2. Push belt tensioning bearing clockwise to release the pressure off the belt to remove the belt. 3. Remove 15/16 nut that holds on the flywheel and remove the flywheel. 4. -
Page 6: Cable
STEPPER CABLE REMOVAL 4000 SERIES Remove hood. (Note) Cable is wrapped counterclockwise starting from the inside going out. (Important note) Do not remove both cable at one time. When replacing cable be sure the ball on the cable lines up with the drive hub hole. -
Page 7: Fuse
CHECK OR REPLACE FUSE 1. This is located under the bike where the power cord connects. 2. Pull out the slot in the bottom of the power supply holder. 3. The fuse is a 15 amp. 5x20mm part#333942224. LOWER BOARD WIRING DIAGRAM FOR STEPPER 4000 SERIES HOW TO REPLACE EPROM 1. -
Page 8: Troubleshooting Guide
TROUBLESHOOTING GUIDE LS & FS 4000 A. PEDALS SPEED UP AND DOWN WITHOUT USER CHANGING SPEEDS 1. CHECK DISPLAY FOR CORRECT SOFTWARE REVISION BY UNPLUGGING THE MACHINE AND THEN PLUG IT BACK IN AND LOOKING AT THE SECOND SET OF LED’s ON THE LEFT ( THE FPM/WATTS WINDOW) a. - Page 9 1. CHECK RIBBON CABLE CONNECTIONS 2. UNPLUG AND PLUG MACHINE TO RESET. 3. REPLACE LOWER BOARD J. NO RESISTANCE ON PEDALS..”SCIFIT” GOES AWAY..CAN PROGRAM. 1. NO SPEED SIGNAL, CHECK FPM READOUT ON THE DISPLAY. ADJUST THE SPEED PICKUP ACCORDING. 2. (2) WHITE WIRES ARE DISCONNECTED GOING TO THE BRAKE.
- Page 10 1. REPLACE UPPER BOARD, RIBBON CABLE, HEART RATE RECEIVER DRILL HOLES IN HOUSING. W. “SCIFIT” SCROLLING DOES NOT GO AWAY AFTER STEPPING UP ON PEDALS 1. CHECK DIP SWITCH SETTING, SHOULD BE 01. 2. CHECK POT ADJUSTMENT ON LOWER BOARD.
