SPECIFICATIONS
MEChANICAL REMOVAL/REPLACEMENT
Step 4:
Use a narrow edge punch and small
dead blow hammer to gently tap the
sleeve clamp (#A5135) outward from the
handlebar tube.
Step 5:
Firmly grab the left handlebar (#A5171)
and pull it completely out of the tube.
Step 6a:
Push the tabs of handlbar inner tube end
plug (#A5134) inward to dislodge it from
PUSH TABS
the handlebar tube.
INWARD
7
