8.1.4 Multicast

Multicast sends a video stream to the multicast group address and allows
multiple clients to acquire the stream at the same time by requesting a copy
from the multicast group address. Therefore, multicast can effectively save
Internet bandwidth. The RTSP (Real-Time Streaming Protocol) controls the
delivery of streaming media.
Click "Enable" to enable Multicast stream 1 or Multicast stream 2. The default
value for multicast address and port are 234.1.2.3 and 10000. Use different
port number for different streams. It is recommended to use the default values.
NOTE - Using the IP address of the Network Camera enables access to
the video. Example: rtsp://192.168.1.1/channel1
Click Apply to apply settings or Cancel to cancel changes.
