b. Adjust the view angle and focus range
i. Release the viewing angle controller bar and then slide it left or right
to adjust the viewing angle. After completion, tighten the viewing
angle controller.
ii. Release the focus controller bar and slide it left or right to adjust the
focus range. After completion, tighten the focus controller.
D. Complete the Installation
a. Place the dome cover on the camera device and slowly turn it until it is
in the desired position.
b. Use the Allen Key and attached four dome screws to secure the dome
cover to the camera device.
