Multicast

Multicast sends a video stream to the multicast group address and allows multiple clients
to acquire the stream at the same time by requesting a copy from the multicast group
address. Therefore, multicast can effectively save Internet bandwidth. The RTSP
(Real-Time Streaming Protocol) controls the delivery of streaming media.
Click "Enable" to enable Multicast stream 1 or Multicast stream 2. The default value for
multicast address and port are 234.1.2.3 and 10000. Use different port number for
different streams. It is recommended to use the default values.
NOTE - Using the IP address of the Network Camera enables access to the video.
Example: rtsp://192.168.1.1/channel1
Click Apply to apply settings or Cancel to cancel changes.
