vi. The chart below the Live View window indicates the activity level of
the Motion Detection window. When motion is detected by the
camera and exceeds the defined threshold, a red bar will appear.
Users can use this feature as a trigger source to send photos or
videos to a remote server via email or FTP.
Click Apply to apply settings or Cancel to cancel changes.

8.3.3 Digital Input (DI)

The DI socket allows the IP camera to receive input from an external device.
The external device should have the ability to drive voltage on the connected
DI wire to the triggering voltage level in order to notify the IP camera of any
event of interest. The IP camera will then process the event notification
according to the specific event rules.
a. Triggering voltage Level: LOW or HIGH. Users should select the
option according to the capability of their external device.
