3) DIDO and Audio Connection
Please refer to the definition of the terminal blocks below. It is
also printed on the motherboard.
Terminal Block
Pin No.
Pin 1
Pin 2
Pin 3
Pin 4
Pin 5
Pin 6
Pin 7
Pin 8
Function
5V
D_0
D_I
DIDO GND
Audio OUT
DGND
Mic/Line in
DGND
12
