Multicast - Brickcom CB-100A series User Manual

Multicast

Multicast sends a stream to the multicast group address and allows multiple clients to acquire
the stream at the same time by requesting a copy from the multicast group address. Therefore,
multicast can effectively save Internet bandwidth. The RTSP (Real-Time Streaming Protocol)
controls the delivery of streaming media. Click to enable Multicast stream 1 / Multicast stream 2.
The default value for multicast address and port are 234.1.2.3 and 10000. Use different port
number for different stream. Use default value is recommended if you are not sure how to
setting.
NOTE - Using the IP address of the camera enables you to view the video.
Example: rtsp://192.168.1.1/channel1
Click Apply or Reset to take effect.
- 36 -
