REFRIGERATION SLIDE-OUT EXPLODED PICTORIAL
The following images show the various parts pertaining to the Refrigeration
Unit (that is slid directly out from lower section) to be serviced.
Condensing Coil
Electrical
(and internal fan)
Junction Box
Refrigeration
Service Valve
Capacitor
Sight Glass
Condensate
Pan
Receiver
Copper
Tubing
Flexible Hose
Condensing
Connections
Unit
Copper
Dryer Filter
Tubing
R
888 Porter Rd. Muskegon, MI 49441 Phone: 231.798.8888 Fax: 231.798.4960 www.structuralconcepts.com
15
