On/Off And On-Hook Key; Alpha Numeric Keys - ASCOM i75 VoWiFi User Manual

User Manual
Ascom i75 VoWiFi Handset
3.2.7

On/Off and On-hook Key

The On/off and On-hook key is used for disconnecting calls and for switching the handset
on and off.
3.2.8

Alpha Numeric Keys

. , - ? ! & @ " ' : ; ( ) / \ _ ^ 1
G H I Ï Ì Î Í 4
P Q R S ß 7
Switch between upper
and lower case.
Add pause "P" in
phone numbers.
In some applications you have the possibility to write letters as well as numbers, which is
indicated by the ABC icon. Pressing the numerical keys will now give you access to the
alphabet plus some special characters according to the picture.
In Stand-by Mode
In stand-by mode short presses on the keys enter the digits, and the characters * and #.
A long press on a key "0" - "9" activates the programmed Hot key function.
In Text Input Mode
In text input mode a press on a key displays the first available character on that specific
key. Press the key repeatedly to view the characters following the first. The marked
character is selected after a time out or when another key is pressed. Press the *-key to
switch between upper case and lower case. Press and hold a key to enter a number in text
input mode, or press repeatedly until the number is shown.
Press and hold the #-key in order to switch between text and number input mode.
In Dialling mode
If a pause is required in a phone number, it is added by making a long press on the *-key.
The pause is indicated with a "P" in the number.
2008-11-10/ Ver. D
Figure 9.
Figure 10.
A B C Å Ä Æ À Á Â Ã Ç 2
Space % $ £ ± + =
¿ < > # ½ µ § ° ¦
D E F È É Ê Ë 3
J K L 5
M N O N Ö Ø Ò Ó Ô Õ 6
T U V Ü Ù Ú Û 8
W X Y Z Ý 9
Switch between text
and number input mode.
Hold
0
TD 92319GB
10
