User Manual
Ascom i75 VoWiFi Handset
Delete a Message stored in the Message list
Open the message list by pressing
Navigate in the list with
question Delete message? is shown; press "Yes".

12.3 Messaging between Handsets

Messaging between handsets is a system dependent function.
Messages from one handset to another is done from the menu entry "Messages". It is also
possible to assign a Soft/Hot key or Service to the "Send message" function.
A Soft/Hot key or a Service can be programmed to send messages either to a predefined
address or to any address in the system. If not predefined, the handset will ask for the
destination address.
An incoming message is immediately displayed and the identity of the sending handset is
shown on a separate row.

12.3.1 Send a Message to another Handset

Press the Menu Soft key, mark the Messages icon and press "Select". Mark "Send
message" and press "Select". Enter the destination address or fetch it from the Local
phonebook by pressing the Soft key with the Contacts icon; press "Select". If the address
is not entered, an error message will be displayed. Enter text and press "Send". Sending
will be displayed as a confirmation of the transfer.

12.4 Send a Message to a predefined Destination Address

Refer to 15.5.9 Edit a Hot key
Create a new Service
Press the Soft key, or press and hold the Hot key, or select the Service. Enter text and press
"Send". Sending will be displayed as a confirmation of the transfer.

12.5 Interactive Messaging

Interactive Messaging (IM) is a function that extends basic messaging. It makes it possible
for a user to access information from a client application in the system, from the handset.
An example can be a customized application that can be accessed from the handset. Data
sent from the handset can be used to initiate the application to send the interactive
message, see
included in the message sent from the application to the handset. The user can then select
one action from the list. The action can be sending a message back to the application,
and/or dialling a specific number etc.
An IM is indicated and viewed the same way as an ordinary message, see 12.2.1, but the
Interactive message icon is added in front of the message. It is saved along with other
messages in the message list.
Interactive Messaging is a system dependent function.
2008-11-10/ Ver. D
, or from the menu, see
. The selected message is marked. Press "Delete". The
on page 48,
on page 44, how to predefine the destination addresses.
12.7 Send Data from the Handset
15.2 Messages
15.5.8 Edit a Soft key on page 47, or
on page 34. A list of actions can be
TD 92319GB
on page 41.
15.4.2
33
