User Manual
Ascom i75 VoWiFi Handset
Select System Set as a Hot key
If you are often moving between systems, it might be convenient to change system
quickly, therefore you can set this function as a Soft key or Hot key.
To change systems: just press the pre-programmed Soft/Hot key to connect to the next
available VoWiFi system (A, B, C or D).
15.5.21 System Information
It is possible to obtain general information about the handset by doing the following:
1
Mark the Settings icon in the menu. Press "Select".
2
Mark "System" and press "Select".
3
Mark "Information". Press "Select" to view information about:
• ESSID: The ID of the system to which the handset is connected.
• IP: The IP address of the handset assigned by the system.
• MAC: The MAC (hardware) address of the handset. This is stored in the handset
and will always be the same.
• SW version: Here you can see which version of the handset software you have.
• Alarm license: If the handset is equipped with a license or not.
Tip: There is a quick access code you can use to enter the information mode directly
without using the menu. The quick access code is *#46#.
15.6 Profiles
1
Enter the menu by pressing the Menu Soft key, or the Navigation key
2
Mark the Profiles icon and press "Select".
Figure 27. The Profiles icon is marked
The handset is equipped with ten Profiles. Two profiles are preset at delivery (Normal and
In charger) and the remaining eight profiles are left for the user to define.
Normal Profile
The Normal profile is the default profile.
In charger Profile
The In Charger profile is activated when the handset is placed in the charger and
deactivated when removed. Your last selected profile is automatically chosen when the
handset is removed from the charger.
2008-11-10/ Ver. D
Figure 42.
TD 92319GB
or
.
51
