User Manual
Ascom i75 VoWiFi Handset
3.2.3

Volume Button

increase
decrease
The Volume button is used for increasing/decreasing the volume. The adjusted volume is
saved in the handset.
3.2.4

Alarm Button

The red Alarm button is used for sending alarms and testing the alarm function (test
alarm). If programmed the handset can automatically dial a predefined telephone number
directly after an alarm is sent.
3.2.5

Mute Button

The Mute button is used for silencing the audible signals in stand-by mode, silencing the
ring signal at an incoming call, and also to turn off/on the microphone during a call.
3.2.6

Soft Keys

Default setting
Figure 2. Navigation key functions in stand-by mode (default).
The three Soft keys are located just beneath the display and the function of each Soft key
is indicated by text in the display just above the keys.
In stand-by mode the Soft keys can be used for specific functions defined by the user of
the handset. The function can be to dial a specific telephone number, sending data, a
short-cut to the Menu, or sending a message.
When navigating in menu mode the Soft keys are used for menu choices.
Note: The Soft key Menu is a default setting but all Soft key settings can be changed by
the user or the system administrator.
2008-11-10/ Ver. D
Figure 5.
Figure 6.
Figure 7.
Figure 8.
Soft keys
TD 92319GB
Optional Soft keys defined by
the user.
Max. seven characters can be
used for naming a Soft key
9
