Ascom i75 VoWiFi Handset
2.4

Keys and Buttons

(menu) left
Figure 5. Navigation key functions in stand-by mode (default).
2.4.1

Navigation Key

The Navigation key controls the movement of the cursor in the display.
In stand-by mode the Navigation key
key for entering the Message list, and the Navigation key
In menu mode, the Navigation key (all directions) is used for scrolling, in the submenus the
Navigation key
Note: These are the default settings for the Navigation key. They can be changed using
the Portable Device Manager.
2.4.2

Off-hook Key

The Off-hook key
2.4.3

On/Off and On-hook Key

The On/off and On-hook key
handset on and off.
2.4.4

Soft keys

Default setting
Soft keys
The three Soft keys are located just beneath the display and the function of each Soft key
is indicated by text in the display just above the keys.
In stand-by mode the Soft keys can be used for specific functions defined by the user of
the handset. The function can be to dial a specific telephone number, sending data, a
short-cut to the Menu, or sending a message.
When navigating in menu mode the Soft keys are used for menu choices.
2006-09-22/ Ver. B
Figure 5.
(message list)
up
right (menu)
down
(call list)
is used for entering the Call list, the Navigation
is used for scrolling through the entries.
is used for connecting calls.
is used for disconnecting calls and for switching the
Figure 6.
TD 92319GB
for entering the menu.
Optional Soft keys defined by
the user.
Max. seven characters can be
used for naming a Soft key
