Page 1: User Manual
TD 92319GB User Manual Ascom i75 VoWiFi Handset 2008-11-10/ Ver. D... -
Page 2: Table Of Contents
1.1 Abbreviations and Glossary ................1 1.2 Versions ......................1 1.3 Functions ......................2 1.4 Accessories ......................2 2 Guideline for Safety and Efficiency for the i75 VoWiFi Handsets ....... 3 2.1 Precautions ......................3 2.2 Environmental Requirements ................4 2.3 Frequency Range ....................4 2.4 Warranty Notification .................. - Page 3 User Manual TD 92319GB Ascom i75 VoWiFi Handset 6.1 Enter/Exit the Menu Mode ................16 7 Menu Tree Structure ..................... 17 7.1 Contacts ......................17 7.2 Messages ......................17 7.3 Call List ......................17 7.4 Services ......................17 7.5 Settings ......................18 7.6 Profiles ......................
- Page 4 User Manual TD 92319GB Ascom i75 VoWiFi Handset 11 Push-to-Talk Conference Call................27 11.1 Send an Invitation to a PTT Group ..............27 11.2 Accept a PTT Conference Call ................ 27 11.3 Reject a PTT Conference Call ................27 12 Messaging......................28 12.1 Message List ....................
- Page 5 User Manual TD 92319GB Ascom i75 VoWiFi Handset 15.1.1 Find an Entry in the Local Phonebook ............. 39 15.1.2 View an Entry in the Local Phonebook ........... 39 15.1.3 Add an Entry to the Local Phonebook ............ 39 15.1.4 Delete an Entry in the Local Phonebook ..........40 15.1.5 Edit an Entry in the Local Phonebook .............
- Page 6 User Manual TD 92319GB Ascom i75 VoWiFi Handset 15.5.21 System Information ................51 15.6 Profiles ......................51 15.6.1 Change between the Profiles ..............52 15.6.2 Change Profile Settings ................52 15.6.3 Set the Profile to Absent On/Off ............. 52 15.6.4 Choose the Profile’s Answering method ..........52 15.6.5 Set the Profile to Divert incoming Calls ...........
-
Page 7: Introduction
TD 92319GB Ascom i75 VoWiFi Handset Introduction The Ascom i75 VoWiFi Handset is part of the Ascom VoWiFi system. With the i75 VoWiFi handset you can maintain connectivity to traditional telephone services while remaining mobile around the work environment. This document describes the features and settings available for the i75 VoWiFi Handset. -
Page 8: Functions
User Manual TD 92319GB Ascom i75 VoWiFi Handset Functions • Local phonebook • Central phonebook • Vibrator • Headset connector • Loudspeaking • Microphone on/off during call • Presence* • Push-To-Talk (PTT)* • Messaging* • Acknowledge* • Interactive messaging* • Group messaging* •... -
Page 9: Guideline For Safety And Efficiency For The I75 Vowifi Handsets
User Manual TD 92319GB Ascom i75 VoWiFi Handset Guideline for Safety and Efficiency for the i75 VoWiFi Handsets Read this chapter before using the i75 VoWiFi Handset. For safe and efficient operation of the handset, observe the guidelines given in this manual and all necessary safety precautions when using the handset. -
Page 10: Environmental Requirements
User Manual TD 92319GB Ascom i75 VoWiFi Handset Battery • Do not immerse the battery into water. This could short-circuit and damage the battery. • Do not expose a battery to an open flame. This could cause the battery to explode. -
Page 11: Warranty Notification
User Manual TD 92319GB Ascom i75 VoWiFi Handset Warranty Notification Do not disassemble the handset. Disassembling the handset voids the warranty. The handset consists of no consumer serviceable components. Service should be performed by Authorized Service centre only. Potentially Explosive Atmospheres Turn the handset off when in an area with a potentially explosive atmosphere. - Page 12 The FCC has granted an equipment authorization for the i75 VoWiFi handset with all reported SAR levels evaluated as in compliance with the FCC RF emissions guidelines. SAR information for the i75 VoWiFi handset is on file at FCC and can be found under the Display Grant section of https://gullfoss2.fcc.gov/prod/oet/cf/eas/reports/...
-
Page 13: Description Of The Handset
User Manual TD 92319GB Ascom i75 VoWiFi Handset Description of the Handset Handset Overview Figure 1. Keys and buttons Visual- and audio parts Figure 1. The i75 VoWiFi handset Microphone Display Loudspeaker Navigation key Off-hook Key Volume Button Alarm Button... -
Page 14: Keys And Buttons
User Manual TD 92319GB Ascom i75 VoWiFi Handset Display The display is an illuminated 128 x 64 pixels LCD, covered by anti-reflex treated plastic glass for maximum readability. Keypad The keypad is illuminated, which makes it possible to operate the handset in dark environments. -
Page 15: Volume Button
User Manual TD 92319GB Ascom i75 VoWiFi Handset 3.2.3 Volume Button Figure 5. increase decrease The Volume button is used for increasing/decreasing the volume. The adjusted volume is saved in the handset. 3.2.4 Alarm Button Figure 6. The red Alarm button is used for sending alarms and testing the alarm function (test alarm). -
Page 16: On/Off And On-Hook Key
User Manual TD 92319GB Ascom i75 VoWiFi Handset 3.2.7 On/Off and On-hook Key Figure 9. The On/off and On-hook key is used for disconnecting calls and for switching the handset on and off. 3.2.8 Alpha Numeric Keys Figure 10. A B C Å Ä Æ À Á Â Ã Ç 2 . -
Page 17: Hot Keys
User Manual TD 92319GB Ascom i75 VoWiFi Handset 3.2.9 Hot Keys Any key “0”–“9” can be set to a Hot key. A Hot key can be programmed to give access to frequently used functions such as dialling a specific handset number, sending data, a short-cut to the menu, or sending a message. - Page 18 User Manual TD 92319GB Ascom i75 VoWiFi Handset The “New voice mail” icon appears when a new voice mail exists. The symbol will remain until all voice mails has been listened to and/ or removed. (Note: This is dependent on voice mail system.) The “Key lock”...
-
Page 19: Handset Memory
User Manual TD 92319GB Ascom i75 VoWiFi Handset The “Read interactive message” icon is added in front of read interactive messages in the message list. The “Action required” icon is added in front of messages where an action is required. -
Page 20: Accessories
User Manual TD 92319GB Ascom i75 VoWiFi Handset Accessories Belt Clip, Swivel-type The ordinary belt clip can be replaced with a special swivel-type belt clip adapted to firmly place your handset onto your belt. Leather Casing The leather casing is especially designed for the handset. The casing comes with a swivel- type belt clip and the handset is fully operational while placed in the casing. -
Page 21: Chargers
User Manual TD 92319GB Ascom i75 VoWiFi Handset Chargers Desktop Charger Figure 12. Figure 4. i75 in Desktop Charger. The Desktop Charger is used for charging your handset, for example at your desk. The tilted design facilitates the use of handsfree operation, for example in loudspeaking mode. -
Page 22: Navigate The Menu
User Manual TD 92319GB Ascom i75 VoWiFi Handset Navigate the Menu The choices in the main menu are displayed graphically with symbols, while the alternatives in the submenus are displayed as a list. Figure 14. Text in the bottom row of the display explains the function of each Soft key. -
Page 23: Menu Tree Structure
User Manual TD 92319GB Ascom i75 VoWiFi Handset Menu Tree Structure Contacts Figure 16. Details Entry 1 (Name: ... Number: ...) • Local phonebook Entry 2 Add, Delete, Edit, Options Search, Delete all, Send Msg Entry 100 Details (Name: ... Number: ...) Entry X •... -
Page 24: Settings
User Manual TD 92319GB Ascom i75 VoWiFi Handset Settings Figure 20. Ring Volume: Silent......level 5 Beep Internal call: Ring signals • Alert signals External call: Medium Callback: Vibrator (on/off) High Key beep (on/off) Mixed Speaker volume: • Audio volumes Handsfree volume: Level 1..........10... -
Page 25: Profiles
User Manual TD 92319GB Ascom i75 VoWiFi Handset Profiles Figure 21. Select Name:..• Normal Ring Volume (Silent, level 1,2..5, ) • In charger Beep Internal call: Edit Options Ring signals External call: Delete* Medium • Profile 2 Callback: Add new profile... -
Page 26: In Call Menu
The right soft key can be configured and used when a call is connected, as a short-cut to different functions. These settings are configured by the system administrator and cannot be set manually in the handset. Refer to Configuration Manual, Ascom i75 VoWiFi Handset, TD 92431GB. -
Page 27: Basic Operation
User Manual TD 92319GB Ascom i75 VoWiFi Handset Basic Operation Switch the Handset On/Off On: Press and hold until the handset begins to start-up. Off: Press and hold until the Shut down view opens. Mark “Switch off” and press “Select”. Switch off is displayed until the handset switches off. -
Page 28: Lock/Unlock The Handset
User Manual TD 92319GB Ascom i75 VoWiFi Handset Lock/Unlock the Handset You can protect your IP handset from being used by others by locking it automatically when placed in a charger or switched off. The handset can only be unlocked with a 1 to 4 digit code. -
Page 29: Calling
User Manual TD 92319GB Ascom i75 VoWiFi Handset Calling Note: The headset answering button is active during a call, or when the handset is ringing. It can also be used to get the line when pre-dialling. Pre-dialling is explained in section 9.3.1 below. -
Page 30: Post-Dial
User Manual TD 92319GB Ascom i75 VoWiFi Handset 9.3.2 Post-dial Press to get the line and enter the number. 9.3.3 Dial Using a Pre-programmed Hot key or Soft key A Hot key or Soft key can be programmed with a telephone number. Press the pre- programmed Hot key or Soft key. -
Page 31: Put A Call On Hold/Retrieve The Call
User Manual TD 92319GB Ascom i75 VoWiFi Handset 9.4.4 Put a Call on Hold/Retrieve the Call Put a call on hold: press “Options” during the call, mark “Hold: (No.)” and press “Select”. The call is put on hold and the text On hold (No.) is shown in the display. -
Page 32: Call Diversion
User Manual TD 92319GB Ascom i75 VoWiFi Handset Call Diversion Either can a Soft key or Hot key be preprogrammed with a short-cut to the “Call diversion” function, or a profile be defined and used for the purpose. Refer to 15.5.8 Edit a Soft key... -
Page 33: Push-To-Talk Conference Call
User Manual TD 92319GB Ascom i75 VoWiFi Handset Push-to-Talk Conference Call Note: The Push-To-Talk function requires a Multi Point Control Unit (MCU), handsets programmed with PTT settings (from the PDM) and that groups have been created in the system. The push-to-talk (PTT) function can be described as a group/conference call. A PTT session can be triggered from the system, by an alarm or by a user that sends an invitation to a PTT group from the handset. -
Page 34: Messaging
User Manual TD 92319GB Ascom i75 VoWiFi Handset Messaging 12.1 Message List The twenty last received messages are stored in a message list, if the total number of data characters does not exceed 20 000. 12.1.1 Display and Scroll between Messages All received messages are saved in the message list. -
Page 35: Read Stored Messages
User Manual TD 92319GB Ascom i75 VoWiFi Handset 12.1.2 Read Stored Messages Open the message as described in 12.1.1. Navigate in the list with . The selected message is marked. Press “Open” to see the whole message. The identity of the sending handset and time and date when the message was received, is shown. -
Page 36: Message Queuing And Message Priority
If no minimum time is set (the parameter is set to 0) the priority order is disabled. Refer to the Configuration Manual i75 VoWiFi Handset. The total number of messages in the queue and the message list can not exceed the total number of characters stored, see 12.1 Message List... - Page 37 User Manual TD 92319GB Ascom i75 VoWiFi Handset queue. If a new message with equal or lower priority is received while another message is read the new message will be placed in the queue. Figure 30. New messages Prio 7...
-
Page 38: Basic Message Handling
User Manual TD 92319GB Ascom i75 VoWiFi Handset 12.2 Basic Message Handling 12.2.1 Receive a Message A flashing LED, accompanied by a message tone and/or a vibrating handset, gives you notice of a message. The message tone can be silenced by a press on the Mute button. If the handset is set in silent mode, the message tone will break trough only if the message is urgent. -
Page 39: Messaging Between Handsets
User Manual TD 92319GB Ascom i75 VoWiFi Handset Delete a Message stored in the Message list Open the message list by pressing , or from the menu, see 15.2 Messages on page 41. Navigate in the list with . The selected message is marked. Press “Delete”. The question Delete message? is shown;... -
Page 40: Interactive Messages With Function Keys
User Manual TD 92319GB Ascom i75 VoWiFi Handset 12.5.1 Interactive Messages with Function Keys If there are function keys specified in an Interactive Message, they will be mapped to the Soft keys and the alphanumeric keys. Function Key ID (A) will be mapped to the left Soft key, Function Key ID (B) will be mapped to the middle Soft key, and Function Key ID (C) will be mapped to the right Soft key. -
Page 41: Presence Management
User Manual TD 92319GB Ascom i75 VoWiFi Handset Presence Management Note: The presence option is only available when the handset has logged into and received an activity list from a Presence Management system, and received time and date from an NTP server. -
Page 42: Alarm Operation
14.4 No-movement Alarm Note: The No-movement alarm requires that the licence option is made available in the handset. For information on how to add a licence, refer to Configuration Manual, Ascom i75 VoWiFi Handset TD 92431GB. You can activate/deactivate the alarm function in the menu, see 15.5.6 Deactivate/... -
Page 43: Man-Down Alarm
14.5 Man-down Alarm Note: The No-movement alarm requires that the licence option is made available in the handset. For information on how to add a licence, refer to Configuration Manual, Ascom i75 VoWiFi Handset TD 92431GB. You can activate/deactivate the alarm function in the menu, see 15.5.7 Deactivate/... -
Page 44: Automatic Alarm After An Emergency Call
User Manual TD 92319GB Ascom i75 VoWiFi Handset 14.8 Automatic Alarm after an Emergency Call By enabling a parameter in the handset an automatic emergency alarm can be triggered after a call to the emergency number. Note: The emergency number is a specific number that can be set in the handset, usually a countrie´s single emergency telephone number that allows a caller to contact the... -
Page 45: Menu Operation
User Manual TD 92319GB Ascom i75 VoWiFi Handset Menu Operation Changes made from the menu are by default saved, but a handset parameter determines if changes are to be saved or not. If this parameter is set to not save, then all changes will be discarded when the handset is restarted. -
Page 46: Delete An Entry In The Local Phonebook
User Manual TD 92319GB Ascom i75 VoWiFi Handset Note: If one or more contacts already have been added, you will have to press “Options” first, then mark “Add” and press “Select”. Enter the name. Change between upper and lower case characters by pressing the *- key on the keypad. -
Page 47: Find An Entry In The Central Phonebook
User Manual TD 92319GB Ascom i75 VoWiFi Handset 15.1.6 Find an Entry in the Central Phonebook Mark the Contacts icon and press “Select”. Mark “Central phonebook”. Press “Search”; Find:_ will appear. Enter a name or number. Press “Search”. For more information about how to search in the Central phone book, see Installation and Operation Manual Phonebook Service, TD 92360GB. -
Page 48: Message List
User Manual TD 92319GB Ascom i75 VoWiFi Handset Select the Messages icon and press the Soft key “Select” to enter the Messages submenu. Figure 36. Figure 22. The Messages icon is marked. 15.2.1 Message List Mark the “Message list” and press “Select”. -
Page 49: Call List
User Manual TD 92319GB Ascom i75 VoWiFi Handset Press “Yes” (“No” will take you back to the Message list); All messages deleted is shown and after one second you will automatically be back in stand-by mode. 15.3 Call List Enter the menu by pressing the “Menu” Soft key, or the Navigation key Mark the Call list icon and press “select”... -
Page 50: Activate A Service
User Manual TD 92319GB Ascom i75 VoWiFi Handset Mark the Services icon. Press “Select”; a list with all created Services is shown. Figure 39. Figure 25. The Services icon is marked. 15.4.1 Activate a Service Mark the Services icon and press “Select”. -
Page 51: Delete A Service
User Manual TD 92319GB Ascom i75 VoWiFi Handset Mark Function:” and press “Select”. Choose a function and press “Select”. Enter data, prefix, phone number, or text message address and text; press “Save”. The handset will automatically return to the Service and the function is marked. -
Page 52: Change The Ring Signal
1.Requires an Alarm License and an i75 Handset equipped with the alarm option. For information on how to add a licence, and how to activate the alarms in the PDM, refer to Configuration Manual, Ascom i75 VoWiFi Handset TD 92431GB. 2008-11-10/ Ver. D... -
Page 53: Edit A Soft Key
User Manual TD 92319GB Ascom i75 VoWiFi Handset Mark “Alarm setting” and press “Select”. Mark “Man-down” and press “Change”; the Man-down checkbox is selected/ cleared. 15.5.8 Edit a Soft key Figure 41. Soft key Left:Menu Middle: Message Right: Not used... -
Page 54: Edit A Hot Key
User Manual TD 92319GB Ascom i75 VoWiFi Handset Choose the desired function for the Soft key. See table below. Soft key/Hot key functions: Data send: Press “Select”. Enter data if you want it to be predefined, or leave it out if you want to enter data after pressing the Soft key, press “Save”. -
Page 55: Change Text Size In Messages
User Manual TD 92319GB Ascom i75 VoWiFi Handset Note: There is a “*” symbol in front of Language, making it easy to find if you have changed language by mistake. Mark the desired language. Press “Select”. The language is shown. The handset will automatically return to the list of general settings. -
Page 56: Enable/Disable Quick Answer
User Manual TD 92319GB Ascom i75 VoWiFi Handset Mark “Auto key lock” and press “Change”. The Auto key lock checkbox is selected/cleared. In stand-by mode a locked keypad is indicated by the Locked keypad icon. 15.5.16 Enable/Disable Quick Answer Mark the Settings icon and press “Select”. -
Page 57: System Information
User Manual TD 92319GB Ascom i75 VoWiFi Handset Select System Set as a Hot key If you are often moving between systems, it might be convenient to change system quickly, therefore you can set this function as a Soft key or Hot key. -
Page 58: Change Between The Profiles
User Manual TD 92319GB Ascom i75 VoWiFi Handset User defined Profiles Eight profiles can be defined and saved by the user. The profiles can, for example, be used to create a special headset profile with different ring signal volume and automatic answer of incoming calls. -
Page 59: Preset Phone Numbers For The Diversions Alternatives
User Manual TD 92319GB Ascom i75 VoWiFi Handset Mark “Call diversions” and press “Select”. You can choose; All calls, On busy, or No answer. Press “Change”. Divert to number:.. is displayed. Enter the telephone number you want to divert to and press “Save”. -
Page 60: System Handling
15.5.20 Select System on page 50. 16.2 Field Upgrade Software and parameters in the i75 VoWiFi Handset can be upgraded by using the Portable Device Manager (PDM). The PDM exists in two versions, Windows version and System version. Refer to the Configuration Manual, Ascom i75 VoWiFi Handset TD 92431GB for more information. -
Page 61: Status Text In Display
User Manual TD 92319GB Ascom i75 VoWiFi Handset Status text in Display 17.1 Accessibility and Voice Quality The base network is not always available. If you do not get in contact with your system, contact your system administrator. For various reasons, some functionality in the system may be inaccessible, causing various status texts to appear. -
Page 62: Environmental Requirements
User Manual TD 92319GB Ascom i75 VoWiFi Handset Call Failed Unable to contact the called handset. User Busy The person being called is already engaged in another call, or has declined your call. Invalid Number The called number does not exist in the system, or the connection between the VoIP Gateway and the PBX is lost. -
Page 63: Maintenance
User Manual TD 92319GB Ascom i75 VoWiFi Handset Maintenance 18.1 Charge the Battery The battery requires charging when the handset is not in use or when the Battery icon in the display shows a low charge. Place the handset in the charger. A beep indicates connection with the charger. The charging status is shown by the battery icon in the handset display. -
Page 64: Change The Clip
Ascom i75 VoWiFi Handset 18.3 Change the Clip A hinge-type belt clip is mounted on the i75 VoWiFi Handset at delivery. The clip can be replaced with a covering plate also included in the delivery, or a swivel-type belt clip that can be ordered separately. -
Page 65: Related Documents
TD 92319GB Ascom i75 VoWiFi Handset Related Documents Data Sheet, Ascom i75 VoWiFi Handset TD 92318GB Quick Reference Guide Ascom i75 VoWiFi Handset M0274030 Configuration Manual, Ascom i75 VoWiFi Handset TD 92431GB Installation and Operation Manual Phonebook Service TD 92360GB... -
Page 66: Document History
2006-09-22 Updated for iteration R2, including SIP. 2007-09-25 • The appendices; Programming the Handset, Upgrade the Firmware, and Add a New i75 VoWiFi Handset to the Site, have been removed and added to the Configuration Manual, Ascom i75 VoWiFi Handset TD 92431GB. -
Page 67: Index
User Manual TD 92319GB Ascom i75 VoWiFi Handset Index Profiles ............ 13 Read interactive message....13, 28 Read message ........12, 28 Services ........... 13 Antenna............7 Settings ........... 13 Signal strength ........11 Battery ............8, 56 Unread message........ 12, 28 Belt clip Invalid Number ..........
