User Manual
Ascom i75 VoWiFi Handset
User defined Profiles
Eight profiles can be defined and saved by the user. The profiles can, for example, be used
to create a special headset profile with different ring signal volume and automatic answer
of incoming calls. Another example is when several users are sharing the same handset.
Each user can then define his own settings, for example; type of ring signal, volume,
answering method, Soft key settings etc. Note that one has to change to the user defined
profiles manually.

15.6.1 Change between the Profiles

1 Mark the Profiles icon and press "Select". A list with all profiles is shown.
2 Mark the Profile you want to change to and press "Select"; the name of the
marked Profile is shown. The handset will automatically return to the list.
A Soft/Hot key can be programmed to change profiles, see
47 for more information.

15.6.2 Change Profile Settings

1 Mark the Profiles icon and press "Select". A list with all profiles is shown.
2 Mark the Profile in which you want to change the settings and press "Options".
3 Mark "Edit:" and press "Select". The handling is then according to the ordinary
settings, see
Absent On/Off, choose answering method, give the profile a new name and to
divert incoming calls.

15.6.3 Set the Profile to Absent On/Off

Follow the instructions described in
settings. Mark "Absent" and press "Change"; the Absent checkbox is selected/cleared.

15.6.4 Choose the Profile's Answering method

1 Follow the instructions described in
profile's settings. Mark "Answer:" and press "Select".
2 Choose the answering method you want. Select between; Ordinary, Auto, Loud, or
Auto loud.
• Ordinary; press
• Auto; the call is automatically connected.
• Loud; press
• Auto loud; the call is automatically connected with loudspeaking function
turned on.
3 When you have chosen type of answering method, press "Select"; the name of the
selected method is shown. The handset will automatically return to the list and the
new answering method is marked.

15.6.5 Set the Profile to Divert incoming Calls

1 Mark the Profiles icon and press "Select". A list with all profiles is shown.
2 Mark the Profile in which you want to change the settings and press "Options".
3 Mark "Edit:" and press "Select".
1.Only applicable with the H.323 protocol
2008-11-10/ Ver. D
15.5 Settings on page 45, but you also have the possibility to set
15.6.2 Change Profile
15.6.2 Change Profile
or the middle Soft key for loudspeaking function.
and the call is connected with loudspeaking function turned on.
15.5.8 Edit a Soft key
Settings, and view the profile's
Settings, and view the
1
TD 92319GB
on page
52
