(3) Display Level: Error logging is
enabled by default.
(4) Mode: Local by default. If
"Remote" or "Local/Remote" is
selected, the system transmits the
log UDP packets to your log server.
Click "Save/Apply".

4.5.3 SNMP Agent

4.5.3.1 Click "SNMP Agent" to display
the window shown in the right figure. You
can enable or disable the SNMP agent
here.
If you click "Enable", you need to set the
values in "Read Community", "Set
Community", "System Name", "System
Location", "System Contact" and "Trap
Manager IP".

4.5.4 Internet Time

4.5.4.1 Click "Internet Time" to display the
window shown in the right figure.
If you enable this function, the system will
automatically obtain the time when access
to the Internet is available.

4.5.5 Access control

4.5.5.1 Service
(1) Click "Access Control" to display
the window shown in the right
figure.
You may enable/disable
FTP/HTTP/ICMP/SNMP/SSH/
TELNET/TFTP services.
(2) Click "Save/Apply" to activate the
settings
