Kraun Wireless ADSL2/2plus Modem Router 54Mbps User Manual page 21

2) Click "Next" to display the window shown
in the right figure.
a. WAN IP Address:
Enter the IP address provided by your
ISP.
b. WAN Subnet Mask:
Enter the subnet mask provided by
your ISP.
c. Use the following default gateway:
You can check this option.
d. Use IP Address:
Enter the IP address provided by your
ISP.
e. Use WAN Interface:
For the broadband access device, you
need to enter the IP address of the
downstream link interface.
3) Use the following DNS server address:
You may check this option.
a. Primary DNS server
b. Secondary DNS server
NOTE: In the IPoA mode, DHCP is not
supported, so you need to manually
enter the WAN IP address, subnet
mask, default gateway, DNS server
and other settings.
4) Click "Next".
a. Enable NAT:
NAT enables multiple computers in
your LAN to use the same WAN IP
address for Internet access. It is
recommended to check this option.
b. Enable Firewall
It is recommended to check this option
to avoid some attacks.
c. Enable IGMP Multicast:
IGMP agent. For example, to enable
the IPTV in the PPPoE mode, you
need to check this option.
d. Enable WAN Service:
Checked by
recommended to keep this default
setting, unless you do not need to
activate your WAN.
Wireless ADSL2/2+ Modem Router 54Mbps
default. It is
21 www.kraun.it
