4.2.5 Routing

4.2.5.1 Default gateway
1) Click "Routing" → "Default Gateway" to
display the window shown in the right
figure.
Enable Automatic
Gateway:
You may check/uncheck this option. If
you uncheck this option, you need to
manually enter the default gateway
address and WAN
recommended to keep the default setting
unchanged.
2) Click "Save/Apply".
4.2.5.2 Static routing
1) Click "Static Route" to display the
window shown in the right figure.
Here, you can add/delete the items of the
static route.
2) Click "Add" to display the window
shown in the right figure. Destination
Network Address: Enter the network or
host for static route.
Subnet Mask: Enter the subnet mask
corresponding to the network or host for
static route.
Use Gateway IP Address: Enter the
gateway address to be passed by the
static route.
Use Interface: Select the interface
corresponding to your connection mode.
Click "Save/Apply".
3) Click "RIP" to display the window shown
in the right figure. Here, you may enable
or disable the global RIP mode. To
enable this mode, you can select the
version: 1, 2 or both. You may also select
the operation mode: Active or Passive.
Click "Save/Apply".
Wireless ADSL2/2+ Modem Router 54Mbps
Assigned Default
service. It is
